CI868 3BSE048845R1 通信模块 可以使用10Mbps或100Mbps的速率

>>>>>型号:CI868 3BSE048845R1  通信模块   可以使用10Mbps或100Mbps的速率

【功能描述】

产品编号:3 bse048845r1

ABB型号:CI868

目录描述:CI868K IEC 61850接口

产品净深度/长度:127.5 mm

产品净高:186mm

产品净宽:59毫米

产品净重:0.7 kg

长描述:包包括:

-CI868，通信接口

-TP867,基板

该模块具有以下特点：

灵活的通信方式：CI868 3BSE048845R1提供了多种通信方式，以适应不同的应用需求。其左侧设有用于通讯扩展（CEX）的插槽，系统提供了多种类型的通讯模件，如Profibus DP、FF、Modbus等，控制器可连接多至12个通讯模件。

高效的数据处理：应用程序可以通过CF闪存卡保存并下载到控制器，也可以通过串口或以太网络装载到目标控制器的RAM内存中（RAM内存需要电池备份）。此外，用户还可以自定义通讯协议，以满足特定的通信需求。

便捷的短信息与长信息传输：模块配备了一个RS232 C口，专门用于短信息的传递，如编程工具等，只提供部分RS232 C信息。另一个通讯口则用于长信息的传输，它提供了完全格式的RS232 C信息，如调制解调器的控制等。

高度的集成性：TP868底板上设有两个RJ45以太网连接器，其中CH1连接器可以使用10Mbps或100Mbps的速率。此外，CI868扩展单元还包含了CEX-Bus逻辑、通信单元和一个DC/DC转换器，该转换器通过CEX-Bus从+24 V电源提供适当的电压。

总的来说，CI868 3BSE048845R1模块是ABB AC 800M控制器在工业自动化和控制系统中的一个重要组件，尤其在需要遵循IEC 61850标准的应用场景中，它提供了稳定、高效的通信解决方案。

【英文介绍】

Product ID:3BSE048845R1

ABB Type Designation:CI868

Catalog Description:CI868K  IEC 61850 Interface

Product Net Depth / Length:127.5 mm

Product Net Height:186 mm

Product Net Width:59 mm

Product Net Weight:0.7 kg

Long Description:Package including:

-CI868, Communication Interface

-TP867, Baseplate

The module has the following features:

Flexible communication methods: CI868 3BSE048845R1 provides a variety of communication methods to adapt to different application requirements. Its left side is provided with a slot for communication expansion (CEX), the system provides a variety of types of communication modules, such as Profibus DP, FF, Modbus, etc., the controller can be connected to up to 12 communication modules.

Efficient data processing: Applications can be saved and downloaded to the controller via a CF flash memory card, or loaded to the target controller's RAM memory via a serial port or Ethernet network (RAM memory requires battery backup). In addition, users can customize communication protocols to meet specific communication needs.

Convenient short message and long message transmission: The module is equipped with an RS232 C port, which is specially used for short message transmission, such as programming tools, etc., which only provides part of RS232 C information. The other communication interface is used for the transmission of long messages, which provides full format RS232 C information, such as modem control.

Highly integrated: The TP868 has two RJ45 Ethernet connectors on the baseboard, of which the CH1 connector can use 10Mbps or 100Mbps rates. In addition, the CI868 expansion unit contains the CEX-Bus logic, communication unit, and a DC/DC converter that delivers the appropriate voltage from the +24 V power supply via the CEX-Bus.

Overall, the CI868 3BSE048845R1 module is an important component of ABB's AC 800M controller in industrial automation and control systems, especially in applications requiring compliance with IEC 61850 standards, it provides a stable and efficient communication solution.
