SENTRY VREL-11 阀门 精确控制流量和压力

>>>>>型号:SENTRY VREL-11  阀门   精确控制流量和压力

【功能描述】

SENTRY VREL-11是一款特别设计用于解决高压采样问题的阀门。该阀门由连接到大管或桶的两个不锈钢管组成，其中锥形杆组件枪管的精密孔中，高压流体得以进入、流过一个杆、转动并流过另一杆，然后流出。其压降是枪管的杆长度的函数，压力在层流条件下平稳降低，通过不连续的压降减少组分的解离。

VREL-11阀门的设计使得样品的压降和流量得到控制，从而可以精确控制流量和压力，无需担心阀门腐蚀或流体分离的问题。同时，所有接液部件均由316不锈钢制成，确保了其在各种环境下的耐用性和稳定性。其工作压力额定值为5000psig（345 barg）在300ºF时，而对于超临界电厂应用，其额定压力为783 psig（538 bar）。

此外，VREL-11阀门还具有在线自清洗的功能，这对于保持持续取样的条件非常有益。在操作中，可以通过转动旋钮从外部控制杆位置，并且在样品流动时进行调整。如果发生堵塞，杆可以缩回，因此系统压力可以将固体物质吹过，实现可变压降和流量控制。

总的来说，SENTRY VREL-11阀门是一款功能强大、设计精良的高压采样阀门，适用于各种需要精确控制流量和压力的场合。

【英文介绍】

The SENTRY VREL-11 is a valve specifically designed to solve high pressure sampling problems. The valve consists of two stainless steel tubes attached to a large tube or barrel, in which the conical rod assembly of the gun barrel in a precision hole, high-pressure fluid can enter, flow through one rod, turn and flow through the other rod, and then out. The pressure drop is a function of the length of the barrel. The pressure decreases smoothly under laminar flow conditions, and the dissociation of components is reduced by discontinuous pressure drop.

The VREL-11 valve is designed so that the pressure drop and flow rate of the sample are controlled, allowing precise flow and pressure control without worrying about valve corrosion or fluid separation. At the same time, all liquid receiving parts are made of 316 stainless steel, ensuring durability and stability in a variety of environments. Its operating pressure rating is 5,000 psig (345 barg) at 300ºF, while for supercritical power plant applications it is rated at 783 psig (538 bar).

In addition, the VREL-11 valve also has the function of in-line self-cleaning, which is very beneficial for maintaining continuous sampling conditions. In operation, the rod position can be controlled from the outside by turning the knob and adjustments can be made as the sample flows. If a blockage occurs, the rod can retract, so system pressure can blow solid material through, enabling variable pressure drop and flow control.

Overall, the SENTRY VREL-11 valve is a powerful, well-designed high pressure sampling valve for a wide range of applications where precise flow and pressure control is required.
