5SHY3545L0016 可控硅模块​ 具有过载和短路保护功能

☆型号：5SHY3545L0016  可控硅模块  具有过载和短路保护功能

【产品详情】

5SHY3545L0016是一款ABB公司的可控硅模块，它在电力和工业应用中具有广泛的应用。作为一款晶闸管硅可控元件，它主要由三个PN结构成，从而形成一个大功率半导体器件。这种设计使得它非常适合用于可控整流、逆变、调压等电路，并可作为无触点开关使用。

该模块的输出触发脉冲具有极高的对称性及稳定性，并且这种稳定性不会随环境温度的变化而受到影响。在现场调试过程中，通常不需要使用示波器即可完成。因此，5SHY3545L0016可控硅触发板可以广泛应用于各种工业领域的电压电流调节，包括电阻性负载、电感性负载、变压器一次侧以及各种整流装置等。

此外，这款可控硅模块还具备冗余控制系统的特点。这意味着它具有高可靠性和稳定性，能够在恶劣的环境下运行，同时提供可调节的电流和电压控制功能，以满足不同负载的需求。它的快速响应时间能够迅速切换负载电流和电压，以满足系统的动态需求。而且，5SHY3545L0016还具有过载和短路保护功能，可以在异常情况下保护负载不受损坏。

总的来说，5SHY3545L0016是一款功能强大、稳定可靠的可控硅模块，适用于各种需要精确和高效控制的电力和工业应用场合。

IGCT在整流环节中与SCR一脉相承，SCR是Silicon Controlled Rectifier的缩写，是可控硅整流器的简称。可控硅有单向、双向、可关断和光控几种类型。它具有体积小、重量轻、效率高、寿命长、控制方便等优点，被广泛用于可控整流、调压、逆变以及无触点开关等各种自动控制和大功率的电能转换的场合单向可控硅是一种可控整流电子元件，能在外部控制信号作用下由关断变为导通，但一旦导通，外部信号就无法使其关断，只能靠去除负载或降低其两端电压使其关断。

【英文介绍】

The 5SHY3545L0016 is an ABB thyristor module that has a wide range of applications in power and industrial applications. As a thyristor silicon controllable element, it is mainly composed of three PNS to form a high-power semiconductor device. This design makes it very suitable for controlled rectifier, inverter, voltage regulation and other circuits, and can be used as a contactless switch.

The output trigger pulse of the module has high symmetry and stability, and this stability will not be affected by the change of ambient temperature. In the field debugging process, usually do not need to use the oscilloscope to complete. Therefore, the 5SHY3545L0016 thyristor trigger board can be widely used in various industrial areas of voltage and current regulation, including resistive loads, inductive loads, transformer primary side and various rectification devices.

In addition, this thyristor module also has the characteristics of redundant control system. This means that it is highly reliable and stable, capable of operating in harsh environments, while providing adjustable current and voltage control functions to meet the needs of different loads. Its fast response time enables quick switching of load current and voltage to meet the dynamic requirements of the system. Moreover, the 5SHY3545L0016 also has overload and short circuit protection, which can protect the load from damage in abnormal conditions.

Overall, the 5SHY3545L0016 is a powerful, stable and reliable thyristor module for a variety of power and industrial applications that require precise and efficient control.

IGCT is in the same vein as SCR in the rectification process, SCR is the abbreviation of Silicon Controlled Rectifier. Thyristors have one-way, two-way, turn-off and light control several types. It has the advantages of small size, light weight, high efficiency, long life, easy control and so on. It is widely used in controlled rectifier, voltage regulation, inverter and contactless switch and other automatic control and high-power power conversion occasions. Unidirectional thyristor is a kind of controlled rectifier electronic component, which can be turned off from off to on under the action of external control signal, but once it is turned on, The external signal cannot be turned off, and it can only be turned off by removing the load or reducing the voltage at both ends.
