ABB UFC718AE101 HIEE300936R0101 HIEE410516P201变频器主板

【产品详情】

UFC718AE101 HIEE300936R0101 HIEE410516P20 变频器在通力电梯中所起的作用是通过变频器内部的电子电路，将380V交流电压进行整流滤波成510V的直流电压，然后在通过控制内部的大功率IGBT管，将510V的直流电压逆变成频率可从0——50HZ可调、电压可从0——380V可调的电压，从而实现电梯在启动加速、匀速运行、减速停层时没有台阶感，消除人们乘坐电梯时的震动感和下沉感，使人们乘坐电梯时更加舒适之功能。因此通力电梯 UFC718AE101 HIEE300936R0101 HIEE410516P20 变频器也成为了通力电梯电气控制系统核心配件之一。

对于通力电梯UFC718AE101 HIEE300936R0101 HIEE410516P20 变频器这个核心的电气配件，您知道它的内部结构组成吗?您懂得它各个接线端子的功用及它的工作原理吗?您懂得它出故障后的检查维修方法吗?

将推出通力电梯 UFC718AE101 HIEE300936R0101 HIEE410516P20 变频器结构组成、控制原理与维修方法系列讲座。下面广州科誉将揭开通力电梯V3F16L变频器面纱，让您一览通力电梯V3F16L变频器内部结构组成。

在通力电梯UFC718AE101 HIEE300936R0101 HIEE410516P20 变频器内部，共有一块主控制电路板、一块电源驱动电路板、一块继电器输出板三大块电路板构成，具体电路实物及它们所起的功能如下。

通力电梯UFC718AE101 HIEE300936R0101 HIEE410516P201 变频器主板的功能是：

(1)接收测速发电机发送的电梯运行速度反馈信号，及信号放大;

(2)接收电梯载重的重量信号，检测电梯曳引电动机的温度;

(3)计算曳引电动机供电频率及电压。

(4)控制驱动柜的驱动板;

(5)控制电梯抱闸的吸和与释放;

(6)与电梯控制系统进行交流，将驱动系统信息实时传递给电梯控制系统，接受控制系统的实时控制信息。

(7)存放电梯启动加速、减速等运行参数;

(8)通过发光二极管显示电梯的运行状态信息

ABB UFC718AE101 HIEE300936R0101 HIEE410516P201变频器主板

【英文介绍】

UFC718AE101 HIEE300936R0101 HIEE410516P20 inverter plays a role in KONE elevator through the electronic circuit inside the inverter, the 380V AC voltage is rectified and filtered into 510V DC voltage, and then through the control of the internal high-power IGBT tube, The inverter of 510V DC voltage can be adjusted from 0 to 50HZ frequency, voltage can be adjusted from 0 to 380V voltage, so as to achieve the elevator in the start of acceleration, uniform speed operation, deceleration stop layer without the sense of step, eliminate the sense of vibration and sinking when people take the elevator, so that people take the elevator more comfortable function. Therefore, KONE elevator UFC718AE101 HIEE300936R0101 HIEE410516P20 inverter has also become one of the core accessories of KONE elevator electrical control system.

For KONE elevator UFC718AE101 HIEE300936R0101 HIEE410516P20 inverter this core electrical accessories, do you know its internal structure? Do you know the function of each terminal and its working principle? Do you know how to check and repair it after it breaks down?

Guangzhou Keyu will launch KONE elevator UFC718AE101 HIEE300936R0101 HIEE410516P20 frequency converter structure composition, control principle and maintenance method series of lectures. The following Guangzhou Keyu will unveil the veil of KONE elevator V3F16L inverter, let you see the internal structure of Kone elevator V3F16L inverter.

In KONE elevator UFC718AE101 HIEE300936R0101 HIEE410516P20 inverter, there is a main control circuit board, a power drive circuit board, a relay output board of three large circuit boards, the specific circuit and their functions are as follows.

Kone elevator UFC718AE101 HIEE300936R0101 HIEE410516P201 inverter motherboard functions are:

(1) Receive the feedback signal of the elevator running speed sent by the tachometer generator, and amplify the signal;

(2) Receive the weight signal of the elevator load and detect the temperature of the elevator traction motor;

(3) Calculate the power supply frequency and voltage of the traction motor.

(4) Control the drive board of the drive cabinet;

(5) Control the suction and release of elevator lock;

(6) Communicate with the elevator control system, transfer the information of the drive system to the elevator control system in real time, and accept the real-time control information of the control system.

(7) Store the elevator starting acceleration, deceleration and other operating parameters;

(8) Display the operating status information of the elevator through the light-emitting diode

ABB UFC718AE101 HIEE300936R0101 HIEE410516P201变频器主板

【其他型号推荐】

【常见问题】

1）备件

2）保修期：12个月！

3）包装：原包装与纸箱。

4）交货时间：付款后3天内发货

5）所有货物将在发货前进行测试。
