SPAD346C3 差动继电器 用于保护双绕组电力变压器

☆型号：SPAD346C3 差动继电器 用于保护双绕组电力变压器

【产品详情】

稳定型差动继电器 SPAD 346 C 设计用于保护双绕组电力变压器和发电机变压器。主要功能包括绕组短路、匝间故障、接地故障和短路保护，以及绕组间短路和极短路保护。此外，继电器可用于保护三绕组电力变压器，前提是电力变压器的短路电源的75%是从同一方向提供的。

SPAD346C3是一款差动继电器，由ABB公司生产。差动继电器是一种用于保护电力系统中的差动电流的设备。差动电流是指流经两个电流互感器的电流之差，通常用于检测线路或设备的故障。

SPAD346C3差动继电器具有以下特点：

高精度测量：采用数字技术设计，能够实现精确的差动保护和测量。

可编程功能：用户可以根据需要进行配置和编程，实现个性化的保护和控制需求。

高可靠性：具有过流保护、过压保护和欠压保护等多种保护功能，确保电力系统的安全和稳定运行。

易于集成：具有标准的接口和通信协议，方便与其他设备进行集成和互联互通。

总的来说，SPAD346C3差动继电器是一款高精度的电力保护设备，适用于各种电力系统中的差动电流保护，能够提高电力系统的安全性和可靠性。

集成三相差动继电器、三相过流继电器和多可配置接地故障保护

产品优势

多功能保护功能

产品特点

集成三相差动继电器、三相过流继电器和多可配置接地故障继电器

三级过流模块，为电力变压器和发电机提供保护，并提供两级备用接地故障保护

在保护区域外和变压器浪涌时，可防止不必要的操作

二次谐波限制，用于防止变压器浪涌时继电器的意外操作

五次谐波约束，用于防止变压器过励磁时出现不必要的继电器操作

宽 CT 比校正范围 - 通过数字设置实现精确校正

4 个用于断路器跳闸的重载输出继电器和 5 个用于信号的输出继电器

5 个可编程外部控制输入

集成断路器故障保护，运行时间可调

差分继电器和接地故障继电器模块，集成了模拟和数字信号的干扰记录器功能

灵敏的相电流和相位角显示有助于检查通电电路连接和矢量组匹配

对电气和电磁干扰的高抗扰度使继电器能够在恶劣的环境中使用

通过对硬件和软件的持续监控实现高可用性和系统可靠性

☆型号：SPAD346C3 差动继电器 用于保护双绕组电力变压器

【英文介绍】

The stable differential relay SPAD 346 C is designed to protect double-winding power transformers and generator transformers. The main functions include winding short circuit, turn fault, ground fault and short circuit protection, as well as winding short circuit and extreme short circuit protection. In addition, relays can be used to protect three-winding power transformers, provided that 75% of the short-circuit power supply of the power transformer is supplied from the same direction.

The SPAD346C3 is a differential relay manufactured by ABB. A differential relay is a device used to protect the differential current in a power system. Differential current refers to the difference between the currents flowing through two current transformers and is usually used to detect faults in a line or device.

The SPAD346C3 differential relay has the following features:

High precision measurement: Designed with digital technology, it enables accurate differential protection and measurement.

Programmable function: Users can configure and program according to their needs to achieve personalized protection and control needs.

High reliability: with over current protection, over voltage protection and under voltage protection and other protection functions to ensure the safe and stable operation of the power system.

Easy integration: With standard interfaces and communication protocols, it is easy to integrate and interconnect with other devices.

In general, the SPAD346C3 differential relay is a high-precision power protection device, which is suitable for differential current protection in various power systems, and can improve the safety and reliability of power systems.

Integrated three-phase differential relay, three-phase overcurrent relay and multiple configurable ground fault protection

Product advantage

Multifunctional protection function

Product characteristics

Integrated three-phase differential relay, three-phase overcurrent relay and multi-configurable ground fault relay

Three-stage overcurrent module provides protection for power transformers and generators, and provides two-stage backup ground fault protection

Unnecessary operations can be prevented outside protected areas and during transformer surges

Second harmonic limit to prevent accidental operation of relays during transformer surges

The fifth harmonic constraint is used to prevent unnecessary relay operation when the transformer overexcites

Wide CT ratio correction range - Accurate correction through digital Settings

Four heavy-duty output relays for breaker trips and five output relays for signals

5 programmable external control inputs

Integrated circuit breaker fault protection, adjustable running time

Differential relay and ground fault relay modules integrate interference recorder functions for analog and digital signals

Sensitive phase current and phase Angle displays help check energized circuit connections and vector group matching

High immunity to electrical and electromagnetic interference enables the relay to be used in harsh environments

Achieve high availability and system reliability through continuous monitoring of hardware and software
