Woodward 9905-704 速度控制器  自动电压调节器

【产品详情】

该装置来自伍德沃德数字同步器和负载控制系列。它设计用于伍德沃德速度控制器（或其他兼容设备）和自动电压调节器，用于并联、同步、加载和卸载三相交流发电机组。

9905-704 DSLC 控制器的一些负载控制功能包括：

频率微调器功能，用于同步负载分配系统中的精确频率控制

简单的负载下降操作可在并行总线应用中提供安全操作

具有独立拾取和压降点的可调负载开关输出

负载升高和降低输入以在同步前调整速度

电压升高和降低输入以在同步前调整电压

该装置具有三相真有效值功率检测，即使在电压波动和相位负载不平衡的情况下也能确保精度。9905-704 DSLC 控制器的额定输入电压为 240 Vac，速度偏置为 +3.0 Vdc。该控制器的额定工作温度为 –40 至 +70 °C（-40 至 158 F），存储温度为 –55 至 +105 °C（-67 至 221 F）。

一些同步器功能包括：

延时自动多色重合闸

电压匹配

自动重新同步

同步器超时报警

Woodward 9905-704 速度控制器  自动电压调节器

【英文介绍】

The unit is from the Woodward digital Synchronizer and Load control family. It is designed for use with Woodward speed controllers (or other compatible devices) and automatic voltage regulators for parallel, synchronous, load and unload three-phase AC generator sets.

9905-704 Some of the load control features of the DSLC controller include:

Frequency trimmer function for precise frequency control in synchronous load distribution systems

Simple load drop operations provide safe operation in parallel bus applications

Adjustable load switch output with independent pick up and pressure drop points

Load raises and lowers input to adjust speed before synchronization

Voltage increases and decreases the input to adjust the voltage before synchronization

The device has three-phase true RMS power detection, which ensures accuracy even in the case of voltage fluctuations and phase load imbalance. The 9905-704 DSLC controller has a rated input voltage of 240 Vac and a speed bias of +3.0 Vdc. The controller is rated for operating temperatures of -40 to +70 °C (-40 to 158 F) and storage temperatures of -55 to +105 °C (-67 to 221 F).

Some synchronizer features include:

Delay automatic multi-color reclosing

Voltage matching

Automatic resynchronization

Synchronizer timeout alarm
