Woodward 9907-032 带扭转滤波器 高压型号

【产品详情】

9907-032 是伍德沃德 723 的高压型号。控制器的额定输入功率为 90 至 150 Vdc（标称值为 125 Vdc），标称功耗为 40 W。像这样的高压型号可以处理 22 A 的浪涌电流，持续 15 ms。这款特殊的 723 型号还有其他三种版本：低压（型号 9907-031）以及带扭转滤波器的低压和高压（型号 9907-033 和 9907-034）。除了电压差和扭转滤波器外，这四种型号是相同的。

伍德沃德 723 型号 9907-032 与数字同步器和负载控制 （DSLC） 兼容。该控制器带有一个 DSLC 单元和最多两个 MPU 或接近开关，用于控制发电机组服务中往复式发动机的负载和速度。723 控件提供了许多定制机会，以满足每个应用程序的特定需求。9907-032 型提供了许多可配置的参数，这些参数在伍德沃德产品手册的“手册”选项卡中进行了概述。

9907-032 有两个 LON 通道。其中一个可用于通过接入 DSLC 单元来监控参数，而另一个可用于通过伍德沃德 LinkNet 输入/输出节点监控功能。发动机和控制参数可以通过Modbus主站设备进行监控，该设备可以使用控制器的串行通道进行连接。伍德沃德 723 数字速度控制单元通过集成诊断功能提供对控制完整性的洞察。这些自诊断测试包括监控基准电源、内存和处理器。

Woodward 9907-032 带扭转滤波器 高压型号

【英文介绍】

The 9907-032 is a high pressure version of the Woodward 723. The controller has a rated input power of 90 to 150 Vdc (nominal 125 Vdc) and a nominal power consumption of 40 W. A high-voltage model like this can handle a 22 A surge current for 15 ms. This particular 723 model is also available in three other versions: low voltage (model 9907-031) and low and high voltage with torsion filters (models 9907-033 and 9907-034). All four models are identical except for the voltage difference and the twist filter.

The Woodward 723 model 9907-032 is compatible with digital synchronizer and Load Control (DSLC). The controller comes with a DSLC unit and up to two MPU or proximity switches to control the load and speed of the reciprocating engine in generator set service. The 723 control provides many customization opportunities to meet the specific needs of each application. The model 9907-032 offers a number of configurable parameters, which are outlined in the "Manuals" TAB of the Woodward product manual.

9907-032 has two LON channels. One can be used to monitor parameters via access to the DSLC unit, while the other can be used to monitor functions via Woodward LinkNet input/output nodes. Engine and control parameters can be monitored via the Modbus master device, which can be connected using the controller's serial channel. The Woodward 723 digital Speed control unit provides insight into control integrity through integrated diagnostics. These self-diagnostic tests include monitoring baseline power, memory, and processor.

Woodward 9907-032 带扭转滤波器 高压型号
