伍德沃德控制器 9906-130 带有 I/O、通信端口、兼容附件等的配置
【产品详情】
9906-130 是 UL、cUL 认证的数字控制。这是 723 系列中的伍德沃德控制器。伍德沃德 723 数字控制器专为各种应用而设计，并提供一些带有 I/O、通信端口、兼容附件等的配置。
用户可配置的通信端口提供了一些用于监视和控制的选项。两个独立的串行接口支持 RS-232、RS-422 或 RS-485 通信。这些端口还具有标准的 ASCII 字符处理功能，允许使用伍德沃德手持式编程器或其他带有 RS-422 串行端口的标准 ASCII 字符计算机终端来调整控制器。伍德沃德 LONTalk 是此 723 控制器的另一个选件。
作为伍德沃德 723 数字控制器的标准配置，9906-130 型具有自诊断功能。诊断测试被集成到系统中，以无缝地确定控制的完整性。自诊断测试包括基线电源、内存和处理器。
另一个标准功能是能够使用模拟或数字速度输入。MPU 和接近开关均由该控制器的双速信号输入支持。两个选项之间的速度输入频率不同。伍德沃德 723 产品规格 02759 提供了有关这两个选项的更多信息。
伍德沃德 723 型号 9906-130 采用钣金机箱，可在 +20 至 +55 °C（+68 至 +131 °F）下处理高达 70 °C （158 °F） 的温度和高达 95% 的湿度。
伍德沃德控制器 9906-130 带有 I/O、通信端口、兼容附件等的配置
【英文介绍】
The 9906-130 is UL, cUL certified digital control. This is a Woodward controller from the 723 series. The Woodward 723 digital controller is designed for a variety of applications and offers some configurations with I/O, communication ports, compatible accessories, and more.
User-configurable communication ports provide several options for monitoring and control. Two independent serial interfaces support RS-232, RS-422 or RS-485 communication. These ports also feature standard ASCII character processing, allowing the controller to be adjusted using a Woodward handheld programmer or other standard ASCII character computer terminal with an RS-422 serial port. The Woodward LONTalk is another option for this 723 controller.
As standard with the Woodward 723 digital controller, the Model 9906-130 features a self-diagnostic function. Diagnostic tests are integrated into the system to seamlessly determine the integrity of the control. Self-diagnostic tests include baseline power, memory, and processor.
Another standard feature is the ability to use analog or digital speed input. Both the MPU and proximity switches are supported by the controller's two-speed signal input. The speed input frequency is different between the two options. The Woodward 723 product specification 02759 provides more information about these two options.
The Woodward 723 Model 9906-130 features a sheet metal chassis that can handle temperatures up to 70 °C (158 °F) and humidity up to 95% at +20 to +55 °C (+68 to +131 °F).
