【产品详情】

8406-114 是由伍德沃德制造的 EGCP-3 发动机发电机控制套件，主控 （MC） 型号。 本机的额定输入电压为 18–32 Vdc，工作温度为 –4 至 +158 °F（存储温度为 –40 至 +185°F）。

该微控制器单元接口具有两个显示面板和一个键盘，用于本地设置/监控和远程 HMI。对于远程 HMI/PLC 连接，可使用 Modbus 或伍德沃德 ServLink 工具将 MC 与远程监控设备连接。四行显示面板用于配置特定站点的要求，以及监控设备运行和警报。

8406-114 必须在使用前通过首次启动菜单进行配置。标准操作的配置点可从前面板显示屏获得。其他配置点（以及标准配置点）可通过 ServLink 通信串行链路从 Watch Window 软件访问。基本操作不需要通过此软件提供的附加功能。

该装置还具有内置安全性，可防止未经授权的配置更改和警报日志清除。配置菜单有五个访问级别，如 MC 操作手册 26195 中所述。使用四位数的安全代码可以访问配置菜单

 8406-114 控制器通信 微控制器单元接口

【英文介绍】

The 8406-114 is an EGCP-3 engine generator control kit, Master control (MC) model manufactured by Woodward. The unit has a rated input voltage of 18-32 Vdc and an operating temperature of -4 to +158 °F (storage temperature of -40 to +185°F).

The microcontroller unit interface has two display panels and a keyboard for local setup/monitoring and remote HMI. For remote HMI/PLC connections, the MC can be connected to a remote monitoring device using Modbus or Woodward ServLink tools. The four-line display panel is used to configure site-specific requirements, as well as monitor device operations and alerts.

8406-114 must be configured through the first startup menu before use. Configuration points for standard operation are available from the front panel display. Other configuration points (as well as standard configuration points) are accessible from the Watch Window software via the ServLink communication serial link. The basic operation does not require additional features provided through this software.

The device also has built-in security that prevents unauthorized configuration changes and alert log erasure. The configuration menu has five access levels, as described in MC Operations Manual 26195. The configuration menu is accessed using a four-digit security code

 8406-114 控制器通信 微控制器单元接口
