8200-1300 汽轮机提供数字控制 数字调速器
【产品详情】
| 特征 | 34 键 |
| 输入电压 | 符合 LVDC （18–32 Vdc） 标准 |
| 制造者 | 伍德 沃德 |
| 工作温度 | –30 °C 至 +70 °C（带显示屏） |
| 屏幕尺寸 | 8.4英寸 |
伍德沃德的 8200-1300 为汽轮机提供数字控制。它是 505 涡轮机控制系列中可用的几种数字调速器之一。本机使用符合标准的 LVDC （18-32 VDC） 电源。
本机可用于非危险场所。它也适用于 I 类 2 分区 A/B/C/D 组位置。该装置通常安装有额定温度至少为 75 摄氏度的绞合铜现场布线。
8200-1300 可以控制单分体式或双分体式执行器汽轮机。它可以配置为工厂DCS（分布式控制系统）的一部分，也可以作为独立单元使用。它设计有五个 PID 控制器，包括一个速度/负载 PID 控制器、一个级联 PID 控制器以及 AUX1 和 AUX2 PID 控制器。该装置提供操作员控制面板，包括图形控制面板显示屏和键盘。该面板包括一个紧急停止按钮、开始、停止、esc 和主页按钮、一个数字键盘和切换向上/向下按钮，以及一个带有向上/向下和向左/向右按钮的回车键。该面板的左侧还有四个 LED，包括 CPU 运行状况、IO 锁定、摘要警报和摘要跳闸。
在内部，8200-1300 包括一个看门狗定时器和一个 CPU 故障电路，用于监控微处理器及其存储器的运行情况。
8200-1300 汽轮机提供数字控制 数字调速器
【英文介绍】
The Woodward 8200-1300 is an integrated graphical front panel HMI designed to control a single or dual (split range) actuator turbine with LVDC (18-32 Vdc) power supply. Woodward's 8200-1300 provides digital control for steam turbines. It is one of several digital governors available in the 505 turbine control series. The unit uses a standard LVDC (18-32 VDC) power supply.
This machine can be used in non-hazardous places. It is also available for Class I 2 partition A/B/C/D group locations. The unit is usually fitted with stranded copper field wiring with a temperature rating of at least 75 degrees Celsius.
The 8200-1300 can control a single or double split actuator turbine. It can be configured as part of a factory DCS (Distributed control System) or used as a stand-alone unit. It is designed with five PID controllers, including a speed/load PID controller, a cascade PID controller, and AUX1 and AUX2 PID controllers. The unit provides an operator control panel comprising a graphic control panel display and keyboard. The panel includes an emergency stop button, start, stop, esc, and home buttons, a numeric keypad and toggle up/down buttons, and a return key with up/down and left/right buttons. There are also four leds on the left side of the panel, including CPU health, IO lock, summary alert, and summary trip.
Internally, the 8200-1300 includes a watchdog timer and a CPU fault circuit to monitor the operation of the microprocessor and its memory.
