WOODWARD 5503-336 远程XCVR模块 单工远程收发器模块

【产品详情】

5503-336，用于伍德沃德系列MicroNet VME机架的远程XCVR模块。该装置通过耐用的铜缆与其相关的主 XCVR 模块接收和发送信息。

单工远程收发器模块 5503-336 XCVR 发送和接收相关主 XCVR 模块的控制数据和地址信息。5503-336 设备连接到主机箱的 VME 总线。机箱解码器确定是否要访问此机箱，如果是，它将激活 5503-336 XCVR 模块以接收或发送信息。

与MicroNet系列中的其他单元相比，5503-336相当简单，因为它在前面只有两个连接用于主XCVR机箱，在后面有两个用于自己的远程XCVR机箱的连接。

远程 XCVR 模块不需要在所有扩展机箱中使用端接电阻器，但链中的最后一个终端电阻器除外。此模块必须安装在 VME 机箱的插槽 1 中。

有关此设备的信息，例如框图和数据表，请参阅上面“手册”选项卡中的手册。

WOODWARD 5503-336 远程XCVR模块 单工远程收发器模块

【英文介绍】

5503-336, remote XCVR module for Woodward series MicroNet VME racks. The unit receives and sends information via a durable copper cable with its associated main XCVR module.

Simplex remote transceiver module 5503-336 XCVR sends and receives control data and address information for the relevant main XCVR module. 5503-336 The device is connected to the VME bus of the main box. The case decoder determines if this case is to be accessed, and if so, it activates the 5503-336 XCVR module to receive or send information.

Compared to the other units in the MicroNet family, the 5503-336 is fairly simple as it has only two connections on the front for the main XCVR case and two connections on the back for its own remote XCVR case.

The remote XCVR module does not require termination resistors in all extension enclosures, except for the last terminal resistor in the chain. This module must be installed in slot 1 of the VME chassis.

For information about this device, such as block diagrams and data sheets, see the manual in the Manual TAB above.
