WOODWARD 5501-467 微网单工电源板 是高压模型

【产品详情】

伍德沃德微网单工电源板 5501-467 在 220 VAC/VDC 的输入电压下工作。该模型被认为是高压模型。板 5501-467 能够用于 MicroNet Plus 或 MicroNet Simplex 机箱。

伍德沃德 5501-467 单工电源板在 <> 伏交流电或直流电的输入电压下工作。该板可以插入MicroNet Simplex或MicroNet Plus机箱，但只能在Simplex系统中运行。该板的一个关键特性是，在MicroNet Simplex机箱中，它在交流电和直流电中都被认为是高压。

当用于Plus和Simplex底盘时，有交流电和直流电的规格。单工机箱和 Plus 机箱中的交流电之间存在差异，例如，Plus 机箱中的最大输入功率为 1250 VA，而单工机箱中的最大输入功率为 1062 VA。两种交流电在最大输入电流方面也有所不同，加号机箱的单工机箱电流为 5.9 A，加号机箱为 6.7 A。

在 5501-467 板的前面板上，有四个 LED 指示灯用于电源健康指示灯，四个 LED 分别是 OK LED、输入故障、电源故障和过热故障。电源故障 LED 用于指示电路板的四个电源转换器中的一个已关闭。您可以检查短路并将其卸下，以尝试再次启动正常操作。如果在短路被移除后，电路板尚未开始正常工作，则必须更换电源。

5501-467板有特定的接线要求，该模块的接线尺寸为十四美式线规或两毫米半平方毫米。请注意，电线的额定温度必须为<>摄氏度。

WOODWARD 5501-467 微网单工电源板 是高压模型

【英文介绍】

Woodward Microgrid simplex power board 5501-467 operates at an input voltage of 220 VAC/VDC. This model is considered a high pressure model. The board 5501-467 can be used in MicroNet Plus or MicroNet Simplex cases.

The Woodward 5501-467 simplex power supply board operates at an input voltage of <> volt AC or direct current. The board can be inserted into a MicroNet Simplex or MicroNet Plus chassis, but can only run in a Simplex system. A key feature of the board is that in the MicroNet Simplex case, it is considered high voltage in both AC and DC.

When used on the Plus and Simplex chassis, there are AC and DC specifications. There is a difference between the AC in a simplex case and a Plus case, for example, the maximum input power in a Plus case is 1250 VA, while the maximum input power in a simplex case is 1062 VA. The two types of AC also differ in terms of maximum input current, with A simplex case current of 5.9 A in a plus case and 6.7 A in a plus case.

On the front panel of the 5501-467 board, there are four LED indicators for the power health indicator, the four leds are OK LED, input fault, power fault and overheat fault. The power failure LED is used to indicate that one of the four power converters on the board is off. You can check for a short circuit and remove it to try to start normal operation again. If the board does not begin to function properly after the short circuit is removed, the power supply must be replaced.

The 5501-467 board has specific wiring requirements, and the wiring size of the module is 14 American wire gauges or two millimeters half square millimeters. Please note that the rated temperature of the wire must be <> degrees Celsius.
