WOODWARD 5466-5000 四通道速度传感器 配置为 MPU 输入

【产品详情】

模块 5466-5000 是一个 MicroNet 四通道速度传感器，配置为 MPU 输入。该模块向后兼容，与单元 5464-658 一起使用。当 5466-5000 模块用于单工系统时，它通过低密度模拟电缆连接到模拟输入 FTM。

模块 5466-5000 是 MicroNet 数字控制器系列的众多速度传感器之一。对于速度传感器，有两种不同类型的传感器输入，涡流和MPU，这个特定的单元是MPU输入速度传感器。该模块通常与带有AppManager服务工具的MicroNet Plus模块一起使用。模块上根本没有电位器，因此该单元不需要校准，更换模块时，只要机箱中使用相同的单元号，模块就不需要任何调整。

5466-5000模块附带了几种规格，其中之一是隔离电压，该器件的隔离电压为4VRMS到控制公共和接地，传感器上的四个通道之间绝对没有电气隔离。此模块有一个编码器规范，即编码器版本 06.5464 或任何更高版本的编码器版本。此设备的兼容性是向后兼容性，但当用作向后兼容设备时，它必须与 658-<> 单元一起使用。

当 5466-5000 单元用于单工型系统并通过单精度电缆连接到单数模拟输入故障转换模块 （FTM） 时，该模块可用于冗余或单工系统。请注意，每个速度输入通道只能接受一个 MPU。

WOODWARD 5466-5000 四通道速度传感器 配置为 MPU 输入

【英文介绍】

The module 5466-5000 is a MicroNet four-channel speed sensor configured as an MPU input. This module is backward compatible and is used with units 5644-658. When the 5466-5000 module is used in a simplex system, it is connected to the analog input FTM via a low-density analog cable.

The module 5466-5000 is one of the many speed sensors in the MicroNet digital controller family. For speed sensors, there are two different types of sensor inputs, eddy current and MPU, and this particular unit is the MPU input speed sensor. This module is usually used in conjunction with the MicroNet Plus module with the AppManager service tool. There is no potentiometer on the module at all, so the unit does not need to be calibrated, and when replacing the module, as long as the same unit number is used in the case, the module does not need any adjustment.

The 5466-5000 module comes with several specifications, one of which is the isolation voltage, the device has an isolation voltage of 4VRMS to the control common and ground, with absolutely no electrical isolation between the four channels on the sensor. This module has an encoder specification, which is encoder version 06.5464 or any later version of the encoder version. The compatibility of this device is backward compatibility, but when used as a backward compatible device, it must be used with the 658-<> unit.

When the 5466-5000 unit is used in a simplex system and connected to a singular analog input Fault conversion module (FTM) via a single precision cable, the module can be used in redundant or simplex systems. Note that only one MPU can be accepted per speed input channel.

WOODWARD 5466-5000 四通道速度传感器 配置为 MPU 输入
