WOODWARD 5466-318  数字控制器  三重模块化冗余内核电源模块

【产品详情】

MicroNet 数字控制器 5466-318 是一款三重模块化冗余内核电源模块。此模块必须与 TMR040 CPU 模块一起使用/匹配。对于其余内核部分，5466-318 单元可以将输入电源调节到 5 VDC 或 10 A。

5466-318模块由伍德沃德公司为MicroNet数字控制系列设计，设计为三重模块化冗余（TMR）内核电源（PS）模块。安装此模块后，它将作为三个内核电源之一用于在MicroNet TMR系统上运行的应用程序。安装后，此模块将插入内核部分的第一个插槽中。请注意，在移除此类模块之前，必须移除 MicroNet TMR 内核电源中的所有模块。

5466-318模块的物理构成是金属的，模块的前面板上只有一个LED。模块面板上的 LED 用于指示设备的电源运行状况。该模块将在来自MicroNet主电源的10伏直流电电源上运行。从主MicroNet电源接收电源后，它将在内核部分的其余部分将其调节为5 A或<> VDC。

安装 5466-318 后，它可以用于许多不同的部分，这些部分如下，非危险位置、I 类、组 A-B-C-D 和分区 2 位置。如果模块安装在非上述位置，则在操作过程中可能会发生潜在错误。

WOODWARD 5466-318  数字控制器  三重模块化冗余内核电源模块

【英文介绍】

The MicroNet Digital controller 5466-318 is a triple modular redundant core power module. This module must be used/matched with the TMR040 CPU module. For the rest of the core, the 5466-318 unit can adjust the input power to 5 VDC or 10 A.

The 5466-318 module was designed by Woodward for the MicroNet digital Control family and is designed as a triple modular Redundant (TMR) core power supply (PS) module. Once this module is installed, it will be used as one of three kernel power supplies for applications running on MicroNet TMR systems. After installation, this module will be inserted into the first slot in the kernel section. Please note that all modules in the MicroNet TMR kernel power supply must be removed before such modules can be removed.

The physical composition of the 5466-318 module is metal, and there is only one LED on the front panel of the module. Leds on the module panel are used to indicate the power health of the device. The module will operate on a 10-volt DC power supply from MicroNet's main power supply. After receiving power from the main MicroNet power supply, it will adjust it to 5 A or <> VDC in the rest of the core section.

After installing 5466-318, it can be used in many different parts, which are as follows, non-hazardous position, Class I, Group A-B-C-D and Partition 2 position. If the module is installed in a location other than the above, potential errors may occur during operation.
