WOODWARD 5466-1520 微网数字控制器 具有网络安全应用

【产品详情】

伍德沃德微网数字控制器5466-1520是一款具有网络安全应用的P1020 CPU。该模型可用于单工和冗余系统。5466-1520 模块有四个通用以太网端口、两个 100 Mbps 端口和两个 1000 Mbps 端口。

5466-1520模块被标记为P1020 CPU，是伍德沃德公司在科罗拉多州柯林斯堡生产的MicroNet数字控制器系列的一部分。该模块的一个关键组件是单元上的双核处理器，该特定的双核处理器为800 MHz。模块上有许多端口，包括两个实时网络端口、一个服务端口、五个CAN端口和四个通用以太网端口。关于四个以太网端口，100 Mbps 和 1000 Mbps 端口各有两个。

通常，MicroNet 系列中的 CPU 模块可以在机箱带电时拆卸和插入，5466-1520 单元也可以实时移除或插入。在卸下此模块之前要注意的重要事项是该模块需要重置，这会通知模块它将被删除，并且将毫不费力地故障转移到第二个CPU模块。该模块将运行几个应用程序，例如网络安全和图形应用程序编程 （GAP） 应用程序。

作为MicroNet-Plus CPU，5466-1520模块可以与冗余或单工系统一起使用，如果CPU用于单工系统，则只有一个CPU，而如果CPU用于冗余系统，则无论有多少个CPU，初始CPU都将插入插槽A1。

在安装模块之前，请参阅三本 26166 手册，有关 5466-1520 模块标准的具体信息，请参见 174V175 手册的第 26166-2 页。

WOODWARD 5466-1520 微网数字控制器 具有网络安全应用

【英文介绍】

The Woodward Microgrid Digital Controller 5466-1520 is a P1020 CPU with network security applications. This model can be used in simplex and redundant systems. The 5466-1520 module has four universal Ethernet ports, two 100 Mbps ports, and two 1000 Mbps ports.

The 5466-1520 module is labeled as a P1020 CPU and is part of the MicroNet family of digital controllers manufactured by Woodward in Fort Collins, Colorado. A key component of the module is the dual-core processor on the unit, which is 800 MHz in this particular case. There are many ports on the module, including two real-time network ports, one service port, five CAN ports, and four universal Ethernet ports. Regarding the four Ethernet ports, there are two each for the 100 Mbps and 1000 Mbps ports.

Typically, CPU modules in the MicroNet family can be removed and inserted when the case is charged, and units 5466-1520 can also be removed or inserted in real time. The important thing to note before removing this module is that the module needs to be reset, which notifies the module that it will be removed and will fail over to the second CPU module effortlessly. The module will run several applications, such as network security and Graphics Application Programming (GAP) applications.

As a MicroNet-Plus CPU, the 5466-1520 module can be used with redundant or simplex systems, if the CPU is used in a simplex system, there is only one CPU, while if the CPU is used in a redundant system, the initial CPU will be inserted into slot A1 regardless of how many cpus there are.

Before installing the module, refer to the three 26166 manuals, for specific information on the 5466-1520 module standard, see page 26166-2 of the 174V175 manual.
