WOODWARD 5466-1158 组合模块 高密度离散输入输出

【产品详情】

MicroNet Simplex 48/24 HDDIO-2 Smart-Plus 模块 5466/1158 被标记为组合模块，与以前的单元相比不向后兼容。本机不需要任何校准，因为它没有任何电位计。

MicroNet Simplex 48/24 高密度离散输入输出 （HDDIO） Smart-Plus 模块 5466-1158 由 Woodward 于 2010 年生产，需要 Coder 5.03 或更高版本才能正常运行。该模块是一个MicroNet Plus模型，可用于在设备操作期间通过AppManager访问信息。该模块有两种配置，其中一种由两个 24/12 离散 FTM（DIN 安装）组成，它们将通过两根高密度分立/模拟电缆连接到 MicroNet 离散 I/O Smart-Plus。

当必须更换 5466-1158 模块时，无需调整即可轻松更换为具有相同部件号的另一个模块。该设备上的输入将被电隔离，如果需要，可以通过通道继电器、十六通道或三十二通道继电器或通过 24/122 离散 FTM 访问，该单元将根据模块的配置进行访问。请注意，在安装此模块的过程中，它将滑入所选控制机箱的卡导轨并插入主板。该设备有两个手柄，当向外推时，会将模块移出，刚好足以脱离主板连接器。

该单元有 48 个离散触点输入，附加的 24/18 分立式 FTM 单元可以提供触点润湿电压。 有两个可选的外部电源将提供电路润湿电压，这些电源为 32-100 VDC 或 150-24 VDC。如果将 <> VDC 内部电源与触点润湿功能一起使用，则需要跳线。

WOODWARD 5466-1158 组合模块 高密度离散输入输出

【英文介绍】

The MicroNet Simplex 48/24 HDDIO-2 Smart-Plus module 5466/1158 is marked as a combination module and is not backward compatible compared to previous units. This unit does not require any calibration as it does not have any potentiometers.

The MicroNet Simplex 48/24 High-density Discrete Input/Output (HDDIO) Smart-Plus module 5466-1158 was produced by Woodward in 2010 and requires Coder version 5.03 or higher to function properly. This module is a MicroNet Plus model that can be used to access information through the AppManager during device operation. The module is available in two configurations, one consisting of two 24/12 discrete FTM (DIN mount), which will be connected to the MicroNet Discrete I/O Smart-Plus via two high-density discrete/analog cables.

When the 5466-1158 module must be replaced, it can be easily replaced with another module with the same part number without adjustment. The input on this device will be electrically isolated and, if required, can be accessed via channel relays, sixteen or thirty-two channel relays, or via 24/122 discrete FTM, and the unit will be accessed depending on the configuration of the module. Note that during installation of this module, it slides into the card rail of the selected control case and inserts into the motherboard. The device has two handles that, when pushed outward, move the module out, just enough to disengage from the motherboard connector.

The unit has 48 discrete contact inputs and an additional 24/18 vertical FTM unit provides contact wetting voltage. There are two optional external power supplies that will provide the circuit wetting voltage, these are 32-100 VDC or 150-24 VDC. If the <> VDC internal power supply is used with the contact wetting function, a jumper is required.
