9903-327 负载和共享控制单元 控制装置访问

【产品详情】

伍德沃德部分 9903-327 系列 2301A 负载分配和速度控制。可通过反向/正向作用控制装置访问，执行器输出最大 7.5 Vdc。

伍德沃德 INC 2301A 负载和共享控制单元 9903-327 是一种控件，可以与同一系列中的另一个控件一起设置，当连接在一起时，使用最小燃料量来控制和供电 9903-327 已连接到的单元。该控制装置可在反向作用和正向作用单元中访问，以便与单个或双执行器一起使用。该控制有多种电压型号，高压或低压，必须与至少包含 15 W 的电源一起使用。

当涉及到速度和相位匹配（SPM）同步器时，控制需要通过屏蔽线连接，并且整个同步器的稳定性需要贯穿整个同步器;同步器和屏蔽不能直接连接。增益电位计在最高顺时针设置下并不总是可以实现峰值性能;有时电位计必须稍有减小，以确保在许多不同条件下的稳定性。

该控制器包含二十九个端子，端子二十和二十一连接单元和执行器，当连接执行器和控制器时，正极引线必须连接到端子二十一，负极端子必须连接到端子二十一;50 号和 <> 号航站楼连接 SPM 和设备。电线的屏蔽层不需要有 <> 毫米或更长的电线暴露，裸露的电线会导致设备无法正常运行。

9903-327 负载和共享控制单元 控制装置访问

【英文介绍】

Woodward Part 9903-327 Series 2301A Load Distribution and speed control. It can be accessed through the reverse/forward acting control, and the actuator output is up to 7.5Vdc.

The Woodward INC 2301A Load and Share Control Unit 9903-327 is a control that can be set up in conjunction with another control in the same family that, when connected together, uses a minimum amount of fuel to control and power the unit to which the 9903-327 has been connected. The control device can be accessed in both reverse and forward acting units for use with single or dual actuators. The control is available in a variety of voltage models, high or low, and must be used with a power supply containing at least 15 W.

When it comes to speed and phase matching (SPM) synchronizers, the control needs to be connected via shielded wires, and the stability of the entire synchronizer needs to be throughout the entire synchronizer; Synchronizer and mask cannot be connected directly. Gain potentiometers do not always achieve peak performance at the highest clockwise setting; Sometimes the potentiometer must be slightly reduced to ensure stability under many different conditions.

The controller comprises twenty-nine terminals, terminals 20 and 21 are connected to the unit and the actuator, when connecting the actuator and the controller, the positive lead must be connected to the terminal 21, the negative terminal must be connected to the terminal 21; Terminals 50 and <> connect SPM and equipment. The shielding of the wire does not need to have <> mm or longer wire exposed, which can cause the device to fail to function properly.
