8272-609 控制机械负载  高压型号

【产品详情】

伍德沃德零件 8272-609 系列 2301A 负载分配和速度控制。90-150 Vdc 至 85-132 V 交流的高电压范围，标称功率为 </= 15 W。

8272-609 型号来自伍德沃德的 2301A 负载分配和速度控制系列。该型号附带的独特控制装置用于为驱动发动机负载的安装提供负载分配和速度控制，这些负载通过变矩器和分轴燃气轮机隔离。

相同的 2301A 速度控制，伍德沃德零件号 8272-609 用于控制两种之一的机械负载;变矩器应用或分流燃气轮机。本机上的速度范围由内部开关设置，并且必须设置为适应特定磁性拾音器要感测的所需频率。

与发电机应用有关，它们通常仅限于燃气轮机。由于 2301A 负载分配和速度控制功能种类繁多，这是控制 N2 动力涡轮机的正常选择，因此该机组是驱动发电机的典型选择。机组的N1压缩机侧或燃气轮机采用2301A调速控制。

高压型号的电源额定值为 90-150 Vdc 至 85-132 Vac，低压型号为 20-40 Vdc。该装置的功耗标称功率为 >15 W。2301A 电子控制装置具有开关可选速度范围。这些控制模型中的任何一个都可以设置为在以下任何速度范围内运行：500 至 1500 Hz、1000 至 3000 Hz、2000 至 6000 Hz、4000 至 12000 Hz。

8272-609 控制机械负载  高压型号

【英文介绍】

Woodward Parts 8272-609 Series 2301A Load Distribution and speed control. High voltage range from 90-150 Vdc to 85-132 V AC, nominal power </= 15 W.

Model 8272-609 comes from Woodward's 2301A load distribution and speed control series. The unique controls included with this model are used to provide load distribution and speed control for the installation of driving engine loads, which are isolated by torque converters and split-shaft gas turbines.

The same 2301A speed control, Woodward Part number 8272-609 is used to control one of the two mechanical loads; Torque converter applications or shunt gas turbines. The speed range on this machine is set by an internal switch and must be set to suit the desired frequency to be sensed by a particular magnetic pickup.

In relation to generator applications, they are usually limited to gas turbines. Because of the 2301A's wide variety of load distribution and speed control functions, which are a normal choice for controlling N2 power turbines, this unit is a typical choice for driving generators. Unit N1 compressor side or gas turbine 2301A speed control.

Power ratings range from 90-150 Vdc to 85-132 Vac for high-voltage models and 20-40 Vdc for low-voltage models. The power consumption of the device is nominal power >15 W. 2301A Electronic control unit with switch selectable speed range. Any of these control models can be set to operate in any of the following speed ranges: 500 to 1500 Hz, 1000 to 3000 Hz, 2000 to 6000 Hz, 4000 to 12000 Hz.
