9907-145
9907-145

9907-145 感应原动机速度 WOODWARD

9907-145 感应原动机速度 WOODWARD 【产品详情】 伍德沃德通电 ProTech 203 超速跳闸设备 9907-145,可通过三个 MPU 感应原动机速度。具有声音和可见警报系统。9907-145 型伍德沃德超速保护装置使用磁性拾音器 (MPU) 来监控原动机速度。这款ProTech通电跳闸系统具有多种功能,使编程和监控MPU功能变得容易。9907-145 系统中的 MPU 与三个

联系人:Sunny

手机:18059884797

QQ:3095989363

邮箱:xiongbagk@gmail.com

产品详情

9907-145 感应原动机速度 WOODWARD




【产品详情】



伍德沃德通电 ProTech 203 超速跳闸设备 9907-145,可通过三个 MPU 感应原动机速度。具有声音和可见警报系统。


9907-145 型伍德沃德超速保护装置使用磁性拾音器 (MPU) 来监控原动机速度。这款ProTech通电跳闸系统具有多种功能,使编程和监控MPU功能变得容易。


9907-145 系统中的 MPU 与三个独立的速度感应单元连接,每个单元都有自己的操作界面。每个接口上都有一个单独的 LED,用于指示该设备 MPU 的状态。如果 MPU 或其接线出现故障,相应的 LED 将亮起。使用 9907-145 型号,操作员可以选择将每台设备配置为同时输出警报和跳闸信号,或者在设备的 MPU 丢失时仅输出警报。


MPU 故障超时、 MPU 失败设定点和 MPU 故障跳闸 是 9907-145 可调参数中的几个。可调参数及其功能的完整列表在伍德沃德ProTech手册85191中。这些参数通过每个操作界面上的键盘和LCD进行编程和监控。速度感应单元可单独编程,但必须使用相同的跳变点进行编程。


由于 9907-145 型的模块化设计,单元单独编程,该设计允许诸如三分之二投票配置和热更换任何单个速度感应单元等功能。由于这些原因,每个单元都有一个单独的 120 Vac/dc 电源(电压范围为 88–132 Vac/90–150 Vdc,7.25 W)。




9907-145 感应原动机速度 WOODWARD





英文介绍





The Woodward Power-on ProTech 203 overspeed trip device 9907-145 can sense the prime mover speed through three MPUs. Audible and visible alarm system.


The Model 9907-145 Woodward Overspeed protection uses a magnetic pickup (MPU) to monitor prime mover speed. This ProTech power-on trip system has a variety of features that make it easy to program and monitor MPU functions.


The MPU in the 9907-145 system is connected to three separate speed sensing units, each with its own operating interface. There is a separate LED on each interface that indicates the status of the device's MPU. If the MPU or its wiring fails, the corresponding LED will light up. With the 9907-145 model, the operator can choose to configure each device to output both an alarm and a trip signal, or to output only an alarm if the device's MPU is lost.


MPU fault timeout, MPU failure set point, and MPU fault trip are a few of the 907-145 tunable parameters. A complete list of tunable parameters and their functions is in the Woodward ProTech manual 85191. These parameters are programmed and monitored via the keyboard and LCD on each operating interface. The speed sensing unit can be programmed separately, but must be programmed using the same jump point.


The units are individually programmed thanks to the modular design of the Model 9907-145, which allows for features such as two-thirds voting configuration and hot replacement of any individual speed sensing unit. For these reasons, each unit has a separate 120 Vac/dc power supply (voltage range 88-132 Vac/ 90-150 Vdc, 7.25 W).
