9905-996 超速保护系统 编程模式

【产品详情】

伍德沃德ProTech 203电子三分之二的超速保护系统。具有 120 电压输入、CPU 和 MPU 故障指示以及可锁定的外壳

Part 9905-996 超速保护装置具有通电跳闸投票器继电器配置。在正常运行期间，投票器继电器处于断电状态。该型号的锁定外壳已通过 IP 65 认证。

锁定的外壳内部是一个钥匙开关，用于访问三个速度感应单元的编程模式。这可以防止未经授权访问型号 9905-996 的编程和测试功能。当设备处于程序模式时，可以设置可调参数。

ProTech 型号 9905-996 可设置为 250 rpm 至 25,000 rpm 的跳闸速度设定点和 100 rpm 至 25,000 rpm 的磁拾音器 （MPU） 故障设定点。这种超速保护型号的跳变点频率范围为 250 Hz 至 25 kHz。完整的产品规格在伍德沃德ProTech手册85196中。

如果一个速度感应单元检测到超速情况，则该单元将跳闸。如果 至少两个速度检测单元检测到超速情况，则三分之二的硬件投票会触发跳闸继电器以使原动机脱机。当跳闸继电器被激活时，跳闸装置的操作员界面LCD上会显示一个代码，LED指示灯亮起，并触发报警输出。

9905-996 超速保护系统 编程模式

【英文介绍】

Woodward ProTech 203 Electronic two-thirds overspeed protection system. Features 120 voltage inputs, CPU and MPU fault indications, and lockable housing

Part 99005-996 Overspeed protection devices have an electrified trip voter relay configuration. During normal operation, the voter relay is powered off. The locked shell of this model has passed the IP 65 authentication.

Inside the locked housing is a key switch for accessing the programming modes of the three speed sensing units. This prevents unauthorized access to the programming and testing functions of Model 9905-996. Adjustable parameters can be set when the device is in program mode.

ProTech models 9905-996 can be set to trip speed setpoints from 250 rpm to 25,000 rpm and Magnetic pickup (MPU) fault setpoints from 100 rpm to 25,000 rpm. This overspeed protection model has a jump point frequency range of 250 Hz to 25 kHz. Complete product specifications are in Woodward ProTech manual 85196.

If a speed sensing unit detects overspeed, the unit will trip. If at least two speed detection units detect overspeed conditions, two-thirds of the hardware votes trigger the trip relay to take the prime mover offline. When the trip relay is activated, a code is displayed on the operator interface LCD of the trip device, and the LED indicator lights up and triggers the alarm output.
