9905-991 超速保护的断电跳闸型号 操作界面
【产品详情】
伍德沃德 ProTech 9905-991 超速保护的断电跳闸型号 203。具有可锁定的外壳、跳闸警报和 220 VAC 输入电压
ProTech 断电跳闸型号 9905-991 采用 IP65 认证外壳。该外壳中有三个独立的、相同的速度感应单元，它们都配有自己的 220 Vac 电源。外壳内有一个钥匙开关，连接到所有三个单元，用于在监视器和程序模式之间切换。外壳被锁定以限制对编程和测试功能的访问。
机柜的前面板上有三个相同的操作界面，三个单元各一个。这些接口均具有 LED 指示灯、双线 LCD、键盘和电位计。当设备处于程序模式时，使用此接口设置 9905-991 参数。当系统处于MONITOR模式时，可以在液晶屏上查看参数、错误代码和其他系统信息。
由于 9905-991 型采用模块化设计，三个速度传感单元可单独编程。但是，它们必须以相同的方式编程才能正常运行。9905-991 型是伍德沃德 ProTech 203 超速保护系统系列的一部分。ProTech 手册 85196 包含有关该设备可调参数的完整信息。该手册还包含一个编程工作表来帮助完成此步骤。
模块化设计也允许该系统的一些关键功能。单元 A、B 和 C 采用三分之二的投票配置。这允许原动机保持在线，即使其中一个单元脱机，无论是测试、更换还是跳闸，操作也能继续。仅当三个单元中的两个单元检测到超速情况时，才会激活系统范围的跳闸继电器 。
9905-991 超速保护的断电跳闸型号 操作界面
【英文介绍】
Woodward ProTech 9905-991 Overspeed protection power trip Model 203. Features lockable housing, trip alarm and 220 VAC input voltage
ProTech power trip Model 9905-991 comes with IP65 certified housing. There are three separate, identical speed sensing units in the housing, each with its own 220 Vac power supply. There is a key switch inside the housing, connected to all three units, for switching between monitor and program modes. The shell is locked to restrict access to programming and testing functions.
The front panel of a cabinet has three identical operation interfaces, one for each unit. These ports feature LED indicators, a two-wire LCD, keyboard and potentiometer. When the device is in program mode, use this interface to set parameters 9905-991. When the system is in MONITOR mode, you can view parameters, error codes, and other system information on the LCD.
Due to the modular design of the Model 9905-991, three speed sensing units can be programmed separately. However, they must be programmed in the same way to function properly. The Type 9905-991 is part of the Woodward ProTech 203 overspeed protection system family. The ProTech manual 85196 contains complete information on the tunable parameters of the device. The manual also includes a programming worksheet to help with this step.
The modular design also allows for some key functions of the system. Cells A, B, and C use a two-thirds voting configuration. This allows the prime mover to remain online and the operation to continue even if one of the units is offline, whether it is testing, replacing, or tripping. The system-wide trip relay is activated only when two of the three units detect overspeed conditions.
9905-991 超速保护的断电跳闸型号 操作界面
