9905-984 数字超速跳闸装置 WOODWARD
【产品详情】
伍德沃德 ProTech 203 单元 9905-984 数字超速跳闸装置，通过三个磁性拾音器 （MPU） 感应原动机速度
部件 9905-984 的前面板有三个操作界面，三个相同的速度感应单元各一个。每个都有双线LCD，触摸板和电位计。每个单元 A、B 和 C 也有单独的 24V 直流电源。
这些前面板操作员界面用于设置参数、监控速度和操作以及显示错误代码。每个单元都有单独的 LED，用于指示 MPU 故障（或其接线故障）、CPU 无法正常工作和单元跳闸等情况。对于某些条件，也可以设置报警输出。
9905-984 型是 ProTech 203 超速保护系统系列的一部分。该系列由伍德沃德制造。ProTech 203 型号 9905-894 超速保护装置每 5 毫秒使用磁拾音器进行一次速度采样，每个速度感应单元中一个。从这些速度样本中，这些单元执行单独的速度计算，然后用于硬件三分之二的投票，以确定是否满足超速条件。如果检测到超速情况，则会激活跳闸继电器。
ProTech 203 型号 9905-984 的其他功能包括：
热更换
在线测试
远程复位
钥匙锁定外壳
当使用可选的不锈钢轮毂时，型号 9905-984 的外壳为 NEMA 4X。有关此 ProTech 203 设备的更多信息和产品规格，请参阅伍德沃德手册 85195。
9905-984 数字超速跳闸装置 WOODWARD
【英文介绍】
The Woodward ProTech 203 Unit 9905-984 digital overspeed tripping device senses the prime mover speed via three magnetic pickups (MPUs)
The front panel of the unit 9905-984 has three operating interfaces, one for each of the three identical speed sensing units. Each has a two-wire LCD, touchpad and potentiometer. Each unit A, B and C also has a separate 24V DC power supply.
These front panel operator interfaces are used to set parameters, monitor speed and operation, and display error codes. Each unit has a separate LED that indicates MPU failure (or its wiring failure), CPU failure, and unit tripping. For certain conditions, you can also set the alarm output.
Model 9905-984 is part of the ProTech 203 overspeed protection system family. The series is manufactured by Woodward. The ProTech 203 Model 9905-894 overspeed protection uses a magnetic pickup for speed sampling every 5 milliseconds, one in each speed sensing unit. From these speed samples, the units perform individual speed calculations, which are then used in a hardware two-thirds vote to determine whether the overspeed condition is met. If overspeed is detected, the trip relay is activated.
Additional features of ProTech 203 Model 9905-984 include:
Hot change
Online test
Remote reset
Key lock case
When using optional stainless steel wheels, the housing for models 9905-984 is NEMA 4X. For more information and product specifications on this ProTech 203 device, please refer to Woodward Manual 85195.
