8200-209 超速保护系统 可以读取三个磁性拾音器

【产品详情】

8200-209 型是 ProTech 203 超速保护系统。它可以读取三个磁性拾音器，速度计算，并根据收集的结果驱动继电器输出。与 8200-209 设备相关的电压输入范围为 88-132 VAC 或 90-150 VDC。

8200-209 型是 120 Vac/dc 输入，是伍德沃德设计的断电跳闸型号，用于 ProTech 203 超速保护系列。当在正确的配置中使用时，该系统与不同的电源组合兼容。

通过三个独立的磁性拾音器 （MPU），该器件每 5 ms 对原动机速度进行采样。8200-209 系统根据三分之二的硬件投票驱动其继电器输出，该投票由三个相同的速度传感单元完成，每个单元执行自己的速度计算。尽管连接这些单独的单元以提供此硬件投票，但系统设计为仅有两个单元联机即可继续运行。

8200-209 超速保护系统的一些功能包括：

远程复位

内置自检

钥匙锁

功能状态指示灯

8200-209 型的模块化设计包括三个速度感应单元中每个单元的单独前面板。该面板有一个触摸板、一个双行 LCD 和一组 LED 指示灯。所有三个单元都有自己的电源，但位于同一个钥匙锁定外壳中，以防止未经授权访问系统的编程。

每个速度感应单元的实际速度可以从设备的前面板查看。在满足超速条件的情况下，如果当前速度达到上一个峰值速度以上，则峰值速度将更新并存储在非易失性存储器中。即使在旅行后，更新和存储也会继续。

8200-209型号的另一个特点是它具有可配置或可编程的参数。其中一个参数示例是当前速度。当前速度参数控制其他参数/设定点，例如 MPU 故障时的跳闸、MPU 故障设定点和跳闸速度设定点。其余参数可在 85206 使用说明书的第 <> 页和第 <> 页上找到。

8200-209 超速保护系统 可以读取三个磁性拾音器

【英文介绍】

Model 8200-209 is ProTech 203 overspeed protection system. It can read three magnetic pickups, calculate the speed, and drive the relay output based on the collected results. The voltage input range associated with the 8200-209 device is 88-132 VAC or 90-150 VDC.

The Model 8200-209 is a 120 Vac/dc input, a power-off trip model designed by Woodward for the ProTech 203 overspeed protection series. When used in the right configuration, the system is compatible with different power supply combinations.

Through three independent magnetic pickups (MPUs), the device samples the prime mover speed every 5 ms. The 8200-209 system drives its relay output based on a two-thirds hardware vote, which is done by three identical speed sensing units, each performing its own speed calculation. Although these individual cells are connected to provide this hardware voting, the system is designed to operate with only two cells online.

Some features of the 8200-209 Overspeed protection system include:

Remote reset

Built-in self-test

Key lock

Function status indicator

The modular design of the Model 8200-209 includes a separate front panel for each of the three speed sensing units. The panel has a touchpad, a two-row LCD, and a set of LED indicators. All three units have their own power supply, but are located in the same keylock housing to prevent unauthorized access to the system's programming.

The actual speed of each speed sensing unit can be viewed from the front panel of the device. In the case of overspeed conditions, if the current speed reaches above the previous peak speed, the peak speed is updated and stored in non-volatile memory. Updates and storage continue even after travel.

Another feature of the model 8200-209 is that it has configurable or programmable parameters. One example of a parameter is the current speed. The current speed parameter controls other parameters/setpoints, such as trip in case of MPU failure, MPU fault set point, and trip speed set point. The remaining parameters can be found on page <> and page <> of the 85206 instruction manual.
