8200-1301 数字调速器涡轮机控制系列 集成的图形前面板

【产品详情】

伍德沃德的 8200-1301 单元是一个集成的图形前面板 HMI，具有 AC/DC（88-132 V 交流或 90-150 Vdc）电源，是 505D 数字调速器涡轮机控制系列的一部分。

8200-1301 是一款伍德沃德 505 数字调速器，设计用于分量程或单个执行器。这是该系列中可用的三个版本之一，另外两个是 8200-1300 和 8200-1302。8200-1301 主要用于 AC/DC（88 至 264 V AC 或 90 至 150 V DC）普通位置兼容电源。它是现场可编程的，并使用菜单驱动的软件来控制机械驱动应用和/或发电机。该调速器可以配置为DCS（分布式控制系统）的一部分，也可以设计为独立单元。

8200-1301 具有几种不同的正常工作模式。这包括配置模式、运行模式和服务模式。配置模式将强制硬件进入 I/O 锁，并将所有输出置于非活动状态。配置模式通常仅在设备的原始配置期间使用。运行模式允许从启动到关闭的正常操作。服务模式允许在设备关闭或正常运行期间进行校准和调整。

8200-1301 的前面板旨在提供多级访问，以便对涡轮机进行调整、操作、校准和配置。所有涡轮机控制功能都可以从前面板执行。它包括使用多个输入按钮控制、停止、启动和保护涡轮机的逻辑算法。

8200-1301 数字调速器涡轮机控制系列 集成的图形前面板

【英文介绍】

Woodward's 8200-1301 unit is an integrated graphical front panel HMI with AC/DC (88-132 V AC or 90-150 Vdc) power supply and is part of the 505D digital governor turbine control family.

The 8200-1301 is a Woodward 505 digital governor designed for use with split ranges or single actuators. It is one of three versions available in the series, the other two being the 8200-1300 and 8200-1302. The 8200-1301 is primarily used for AC/DC (88 to 264 V AC or 90 to 150 V DC) common position compatible power supplies. It is field programmable and uses menu-driven software to control mechanical drive applications and/or generators. The governor can be configured as part of a DCS (distributed control System) or designed as a stand-alone unit.

The 8200-1301 has several different normal operating modes. This includes configuration mode, run mode, and service mode. Configuration mode forces the hardware into an I/O lock and puts all output in an inactive state. Configuration mode is usually used only during the original configuration of the device. Run mode allows normal operation from startup to shutdown. Service mode allows calibration and adjustment during equipment shutdown or normal operation.

The front panel of the 8200-1301 is designed to provide multiple levels of access to tune, operate, calibrate and configure the turbine. All turbine control functions can be performed from the front panel. It includes logical algorithms that use multiple input buttons to control, stop, start, and protect the turbine.
