8440-1856 2000系列8440-1856控件

【产品详情】

Woodward EasyGen 2000系列8440-1856控件，在设置控件时，有几种电线尺寸可供选择，以便与控件配对。可以与844-1856控件配对的AWG线尺寸之一是10 AWG线，该线的平方毫米将等于6。

控制器的发电机电压可以在几个不同的端子上测量，这些端子是端子14到端子21。如果使用端子十八和十九，发电机电压将在120伏读端子十八和480伏读端子十九。

在操作控件时，在查看终端主屏幕时，您将观察到几个基本部分。会有价值;显示准确运行信息的状态和报警信息;单线图和软键。控制屏幕上的软键允许在级别和功能之间进行导航，以及操作和配置。

在使用控制装置时，如果您在操作过程中使用停止模式，请非常小心，它在任何情况下都不能与控制装置上的紧急停止系统相同。如果您正在使用紧急停止输入，它将在状态和警报信息中被编程为f级警报。

8440-1856 2000系列8440-1856控件

【英文介绍】

The Woodward EasyGen 2000 series 8440-1856 control is available for purchase, repair, or refurbishment at AX Control INC.  When setting up your control there are several wire sizes that you can choose from to pair with your control.  One of the AWG wire sizes that can be paired with the 844-1856 control is the 10 AWG wire, the square millimeter of this wire will equal six.

The generator voltage of the control can be measured on several different terminals, the terminals being terminals fourteen through terminal twenty-one.  If using terminals eighteen and nineteen the generator voltage will be reading at 120 Vac for terminal eighteen and 480 Vac for terminal nineteen.

When operating the control when looking at the main screen of the terminal there are several basic sections that you will observe.  There will be values;  status and alarms messages which show accurate operating information;  a single-line diagram, and softkeys.  The softkeys on the control screen allow for navigation between levels and functions, along with operation and configuration.

Be extremely careful that while using your control if you use the stop mode during operation that it under no circumstances is the same as the emergency stop system on the control.  If you are using an emergency stop input it will be programmed within the status and alarms message as an F-class alarm.

8440-1856 2000系列8440-1856控件
