WOODWARD 8200-1300 模块连接器

WOODWARD 8200-1300 模块连接器

8200-1300 是 50 年气体检测经验的产物。该控制器可以灵活地接受来自可燃气体、有毒气体和氧气探测器、火焰、热量和烟雾探测器以及手动呼叫点的输入。

设计为模块化系统，该功能可以通过为用户应用程序 定义的系统控制和警报属性进行扩展和定制。由控制卡、将各种火灾和气体探测器连接到控制卡的接口卡组成。工程卡用于调试、维护、系统健康检查和报警级别审计。

控制器卡火气控制卡可以插在同一个机架上。

5701气控卡为单通道操作，5704气控卡可实现四路操作。每张卡有两个输入 4-20mA 和 mV 用于催化检测。显示气体读数，并可以图形格式查看。峰值读数和传感器性能也受到监控。观看模式可以在单个或组合频道之间更改。三级报警和个人、分区、投票、主控、延时、更新和上升率报警设施选项。

5704F 火控卡有四个火区输入，适合与火焰、烟雾、热探测器和手动呼叫点配对。LED 指示各个火区的状态。每张卡有两条线路监控报警输出，19 英寸机架中可能有 15 张卡，可提供 60 个火区。接口卡有 9 个版本的接口卡可供选择（5 个用于 5701 气体，2 个用于 5704 气体，2 个用于 5704 消防控制卡）接受 2.5 毫米 14 规格电缆。每个都有继电器选项和单独的控制卡电源选项。串行通信

串行通信模块可与远程设备（DCS、PLC 或 SCADA 包）配对，从而实现通道监控、检查和配置。• MODBUS RTU 协议• 数字 RS485 / 422 / 232 标准• 双向

WOODWARD 8200-1300 模块连接器

8200-1300 is the product of 50 years of gas detection experience. The controller can flexibly accept inputs from combustible gas, toxic gas and oxygen detectors, flame, heat and smoke detectors and manual call points.

Designed as a modular system, this function can be extended and customized through system control and alarm attributes defined for user applications. It consists of a control card and an interface card that connects various fire and gas detectors to the control card. Engineering cards are used for debugging, maintenance, system health check and alarm level audit.

Controller card The fire and gas control card can be plugged into the same rack.

The 5701 air control card is single-channel operation, and the 5704 air control card can realize four-channel operation. Each card has two inputs 4-20mA and mV for catalytic detection. Displays gas readings and can be viewed in graphic format. Peak readings and sensor performance are also monitored. The viewing mode can be changed between single or combined channels. Three-level alarm and personal, zoning, voting, master control, delay, update and rate of rise alarm facilities options.

The 5704F fire control card has four fire zone inputs, which is suitable for pairing with flame, smoke, heat detector and manual call point. LED indicates the status of each fire zone. Each card has two lines to monitor the alarm output, and there may be 15 cards in a 19-inch rack, which can provide 60 fire zones. There are 9 versions of interface cards to choose from (5 for 5701 gas, 2 for 5704 gas and 2 for 5704 fire control card) to accept 2.5mm 14-gauge cables. Each has a relay option and a separate control card power option. serial communication

The serial communication module can be paired with remote equipment (DCS, PLC or SCADA package) to realize channel monitoring, inspection and configuration.

Modbus RTU protocol

Digital RS485/422/232 standard

two-way
