810-370141-001 压力转换器 精确的流体压力控制

>>>>>型号:810-370141-001     压力转换器  精确的流体压力控制

【功能描述】

伍德沃德的第二二代电流压力变流器(CPC-11) 10 bar、2区、单工版本具有增强的动态性能，是用于定位单作用蒸汽轮机阀伺服器/执行器的电液压力调节控制阀。

CPC-1解决了行业头可靠性问题之-，即油污染影响设备正常运行时间和性能。

CPC-I1接授4-20 mA的压力需求信号,并精确控制油压以精确定位单作用蒸汽轮机调速阀。精确稳定的蒸汽阀控制直接关系到蒸汽轮机速度和负载控制的提高以及系统机械磨损的减少。

特征:

耐油污(ISO20/16)

精确的流体压力控制

稳定和线性的阀门控制

包含阀门线性化表(全量程<0.2%)

于关键应用的冗余输入传感器

接受来自冗余控制器的信号

冗余(双) CPC (主从)功能

标准安装和液压连接

自清洗阀算法

状态和健康指示(压力传感器健康、输入需求信号健康、内部单元健康、输入电源质量)

控制压力读数

具有趋势的软件服务工具

北危险场所认证

符合适用的CE指令- ATEX. 机械、PED和EMC

【英文介绍】

Woodward's second generation Current Pressure converters (CPC-11), 10 bar, 2-zone, simplex version with enhanced dynamic performance, are electro-hydraulic pressure regulating control valves for positioning single-acting steam turbine valve servers/actuators.

CPC-1 addresses one of the industry's leading reliability issues - oil contamination affecting equipment uptime and performance.

The CPC-I1 receives a pressure demand signal of 4-20 mA and precisely controls the oil pressure to precisely position the single-acting steam turbine governing valve. Accurate and stable steam valve control is directly related to the improvement of steam turbine speed and load control and the reduction of mechanical wear of the system.

Features:

Oil resistance (ISO20/16)

Precise fluid pressure control

Stable and linear valve control

Includes valve linearization table (full range <0.2%)

Redundant input sensors for critical applications

Accepts the signal from the redundant controller

Redundant (dual) CPC (master/slave) function

Standard mounting and hydraulic connections

Self-cleaning valve algorithm

Status and health indicators (pressure sensor health, input demand signal health, internal unit health, input power quality)

Control pressure reading

Software service tools with trends

North Hazardous Site certification

Compliance with the applicable CE Directive - ATEX. Machinery, PED and EMC
