>>>>>型号:8200-1300 505涡轮机 监控微处理器及其存储器
【功能描述】
伍德沃德的8200-1300为蒸汽透平机提供数字控制。它是505涡轮机控制系列中几种可用的数字调速器之一。该设备使用符合标准的LVDC (18-32VDC)电源。
该装置可用于非危险场所。也适用于类,Div。 2、组织A/B/C/D位置。该装置通常安装有额定温度至少为75摄氏度的绞合铜现场布线。
8200-1300可以控制单或双分程致动器汽轮机。它可以配置为工DCS(分布式控制系统)的一部分, 也可以作为独立单元使用。它设计有五个PID控制器,包括速度/负载PID控制器、串级PID控制器以及AUX1和AUX2 PID控制器。该装置提供一个带 有图形控制面板显示器和键盘的操作员控制面板。该面板包括-个紧急停止按钮、开始、停止、esc和主页按钮、-个数字键盘、 向上向下切换按钮以及-个带有向上向下和向左/向右按钮的回车键。.面板左侧还有四个led,包括CPU健康、I0锁定、 汇总警报和汇总跳闸。
在内部,8200-1 300包括-个看]狗定时器和一个CPU故障电路,以监控微处理器及其存储器的运行。
【英文介绍】
Woodward's 8200-1300 provides digital control for steam turbines. It is one of several digital governors available in the 505 turbine control series. The device uses a standards-compliant LVDC (18-32VDC) power supply.
The device can be used in non-hazardous places. Also applies to classes, Div. 2. Organize A/B/C/D positions. The unit is usually fitted with stranded copper field wiring with a temperature rating of at least 75 degrees Celsius.
The 8200-1300 can control single or double split actuator turbines. It can be configured as part of a working DCS(distributed control System) or used as a standalone unit. It is designed with five PID controllers, including the speed/load PID controller, cascade PID controller, and AUX1 and AUX2 PID controllers. The unit provides an operator control panel with a graphical control panel display and keyboard. The panel includes an emergency stop button, start, Stop, esc, and home buttons, a numeric keypad, a toggle up and down button, and a return key with up and down and left/right buttons. There are also four leds on the left side of the panel, including CPU Health, I0 lock, summary alert, and summary trip.
Internally, the 8200-1 300 includes a dog timer and a CPU fault circuit to monitor the operation of the microprocessor and its memory.
