TD000A 控制卡模块 CPU模块

【产品详情】

HITACHI控制模块日立PLC可编程控制器MVH系列CPU模块

除了用于PC的USB和串行端口(RS-232C)外,以太网和USB存储器端口是标准设备。

40点型和64点型8种机型阵容通过通用USB存储器轻松读取/写入程序，并配备数据记录/跟踪(CSV 文件保存)功能配备Modbus网关功能

(Modbus-TCP台Modbus-RTU协议转换功能)

高速计数器(100kHz)x 5通道

脉冲/PWM输出(65kHz)x 3通道

①接收由控制目标给出的输入信号，根据用户设定程序内容进行运算并输出运算结果。另外，可以将操作结果与程序信息可保存在内部输出区城。

②为本体供电，并开始运行系统，连续执行①的运作直到断电或系统停止运行。

③内部保存的信息可以通过外部连接的设备提取或设为其他信息。同时，当系统开始运行时，这些信息可自动初始化或由用户设定保存这些信息。

④运行状态可由每个单元的L ED或外接设备显示确认。

下述功能用于用户设定或确认运行状态:

①DIP开关(基本单元用于设定CPU通信功能和运行模式等(不包括10点类型

②RUN开关(基本单元指示运行、停止。(对于10类点类型为外部输人)D LED显示基本单元和扩展单元指示电源系统状态，运行状态和1o操作状态。

④通信连接器(基本单元用于通过RS-232C, RS 485，RS-422 连接外部设备。(只有23和28点类型具 有RS 485. RS -422)

⑤扩展连接器(基本单元和展单元用于扩展输人/输出(不包括10点类型

⑥接线端模块(基本单元和扩展单元用于连接电源，进行和控制日标的信号提取。

TD000A 控制卡模块 CPU模块

【英文介绍】

HITACHI Control module Hitachi PLC Programmable controller MVH series CPU module

In addition to USB and serial ports (RS-232C) for PCS, Ethernet and USB memory ports are standard devices.

40-point and 64-point models 8 model lineup with easy read/write programs via universal USB memory and equipped with data logging/tracking (CSV file saving) function with Modbus gateway function

(Modbus-TCP station Modbus-RTU protocol conversion function)

High speed counter (100kHz)x 5 channels

Pulse /PWM output (65kHz)x 3 channels

① Receive the input signal given by the control target, calculate and output the result according to the user-set program content. In addition, the operation results and program information can be saved in the internal output area.

(2) Supply power to the body, and start running the system, and continue to perform the operation of (1) until the power is off or the system stops running.

Information stored internally can be extracted or set as other information by an externally connected device. At the same time, when the system starts running, this information can be automatically initialized or saved by the user.

④ The operating status can be confirmed by the L ED or external equipment display of each unit.

The following functions are used by the user to set or confirm the operating status:

DIP switch (The basic unit is used to set the CPU communication function and operation mode, etc. (excluding the 10-point type)

②RUN switch (The basic unit indicates running and stopping. (For 10 class point types external input)D LED displays basic unit and expansion unit indicating power system status, operating status and 1o operating status.

④ Communication connector (The basic unit is used to connect external devices through RS-232C, RS-485, RS-422. (Only 23 and 28 point types have RS 485.RS-422)

⑤ Expansion connector (base unit and expansion unit are used to expand input/output (excluding 10-point type)

⑥ Terminal module (basic unit and expansion unit are used to connect the power supply, carry out and control the sun signal extraction.
