Tews Technologies TPMC871是一个标准的单宽32位PMC模块，有一个用于16位PC卡或32位Cardbus卡的接口，使用PC卡控制器和电源管理单元。PC卡控制器的寄存器映射与Intel 82365-DF兼容。

电源管理单元提供3.3V或5.0V PC卡电源和3.3V、5.0V或12V PC编程电压、由于电源管理单元的短路和热保护，模块上不需要外部保险

然

TPMC871提供与PCMCIA 2.1/JEIDA 4.2标准兼容的16位C卡的完整EXCA寄存器实现。支持内存卡和/0卡，PC卡16多可访问五个内存窗口和两/0裔口，对于32位Cardbus卡，控制器支持两内存窗口和两人/0窗口，(ardbus卡状本信息可以在Cardbus套接字客存器中访问这些寄存器可以映射到主机内存空间中。

TEWS TPMC871-50 工控模块

Tews Technologies TPMC871 is a standard single-width 32-bit PMC module with an interface for 16-bit PC cards or 32-bit Cardbus cards, using a PC card controller and power management unit. The PC card controller's register map is compatible with Intel 82365-DF.

The power management unit provides 3.3V or 5.0V PC card power supply and 3.3V, 5.0V or 12V PC programmed voltage. No external insurance is required on the module due to the short circuit and thermal protection of the power management unit

However,

The TPMC871 provides a full EXCA register implementation for 16-bit C cards compatible with the PCMCIA 2.1/JEIDA 4.2 standard. Support for memory cards and /0 cards, PC card 16 can access more than five memory Windows and two /0 ports, for 32-bit Cardbus cards, the controller supports two memory Windows and two /0 Windows, (ardbus card file information can be accessed in Cardbus socket storage These registers can be mapped to the host memory space.
