IC693PWR330H 高容量电源 输入过压保护器件

☆型号：IC693PWR330H 高容量电源 输入过压保护器件

【产品详情】

IC693PWR330 是一款高容量电源，具有 30 瓦输出和 120/240 VAC/125 VDC 输入。有些应用可能需要高+5V电流容量，而标准电源（IC693PWR321）可能不具备这些容量。因此，这种高容量电源允许利用+5V电源的30瓦功率。IC693PWR330可以在 85 至 264 VAC 或 100 至 300 VDC 范围内的输入电压源下工作。该电源提供 +5 VDC 输出、+24 VDC 继电器电源输出，可为 90-30 系列输出继电器模块上的电路分配电源。某些模块内部使用的隔离式 +24 VDC 可用于为 24 VDC 输入模块提供外部电源。IC693PWR330具有用于 AC/DC 输入电源的现场接线连接。这两个电源由 6 个用于用户连接的端子组成。这些链接包括;交流电源、20 VAC 电源和 240 VAC 电源的地线。它们通过电源正面的前 3 个端子连接到系统。它们对 AC/DC 输入电源的灵敏度通常较低。

IC693PWR330包含输入过压保护器件，这些器件在用户端子排上的引脚 4 上有一个内部连接。该引脚与引脚 3 相连，并提供在公司设置良好的捆绑跳线。如果引脚 3 和 4 都不需要过压保护，则可以移除绑带跳线，使该字符不起作用。它还需要过流保护，该保护由 5V 逻辑输出提供，该输出在电子上限制为 3.5 安培（高容量电源为 7 安培）。每当有过大负载时，就会在内部感应到它，这可能会导致电源关闭。在发生此类情况时，输入中的内部保险丝充当备用电源。它还可以保护电源免受内部电源故障的影响。

技术规格

额定电压： 120/240 VAC 或 125 VDC

输入电压范围： 85 至 264 VAC 或 100 至 300 VDC

输入功率： 100VA（带 VAC）或 50 W（带 VDC）

负载能力： 30 瓦

底板上的位置： 最左边的插槽

通信： RS 485 串口

☆型号：IC693PWR330H 高容量电源 输入过压保护器件

【英文介绍】

The IC693PWR330 is a high capacity power supply with 30 watts output and 120/240 VAC/125 VDC input. Some applications may require high +5V current capacities that may not be available with standard power supplies (IC693PWR321). Therefore, this high capacity power supply allows the utilization of 30 watts of power from a +5V power supply. The IC693PWR330 can operate at input voltage sources in the range of 85 to 264 VAC or 100 to 300 VDC. This power supply provides +5 VDC output and +24 VDC relay power output to distribute power to the circuits on the 90-30 series output relay modules. The isolated +24 VDC used inside some modules can be used to provide external power to 24 VDC input modules. The IC693PWR330 has field wiring connections for AC/DC input power. The two power supplies consist of six terminals for user connection. These links include; Ground cables for AC, 20 VAC and 240 VAC power supplies. They are connected to the system through the first 3 terminals on the front of the power supply. They are generally less sensitive to AC/DC input power supplies.

The IC693PWR330 contains input overvoltage protection devices that have an internal connection on pin 4 on the user terminal block. This pin is connected to pin 3 and provides a bundle jumper that is well set in the company. If pins 3 and 4 do not require overvoltage protection, the binding jumper can be removed so that the character is not active. It also requires overcurrent protection, which is provided by a 5V logic output that is electronically limited to 3.5 amps (7 amps for high-capacity power supplies). Whenever there is an excessive load, it is sensed internally, which may cause the power to shut down. When this happens, the internal fuse in the input acts as a backup power source. It also protects the power supply from internal power failures.

Technical specification

Rated voltage: 120/240 VAC or 125 VDC

Input voltage range: 85 to 264 VAC or 100 to 300 VDC

Input power: 100VA with VAC or 50W with VDC

Load capacity: 30 watts

Location on the bottom plate: leftmost slot

Communication: RS 485 serial port
