IS220PDOAH1A 分立式输出包 反馈信号

【产品详情】

IS220PDOAH1A型号采用分立式输出包，在设计时考虑了连接多达两个 I/O 以太网网络和其他分立式输出端子板。该型号的一个特殊功能是它可以控制多达 12 个继电器，并接受来自其他端子板的反馈信号。可用于此型号的典型继电器是固态继电器和电磁继电器。固态继电器与 TRLYH1B、C、D 和 F 端子一起使用，而电磁继电器与TRLYH1E板一起使用。此电池组将接收的输入来自双 RJ45 以太网连接器以及三针电源输入。

IS220PDOAH1A包中嵌入了一个处理器板。有多个处理器，包括但不限于状态指示 LED、用于监控和排序的本地电源、包括闪存和 RAM 存储器的高速处理器等等。有关处理器的所有信息都可以在 GEH-721G Mark VIe 控制系统指南中找到，信息可以在第 223 至 230 页找到。

有一个与IS220PDOAH1A包一起使用的输出使能功能。在为电池组供电的应用中，所有输出将被禁用，直到完成一些内部自检。使能功能可以提供独立于命令的路径，这将确保继电器在电池组的初始化和上电期间保持脱落状态。

IS220PDOAH1A 分立式输出包 反馈信号

【英文介绍】

The IS220PDOAH1A model features a discrete output package designed with up to two I/O Ethernet networks and other discrete output terminal boards in mind. A special feature of this model is that it can control up to 12 relays and receive feedback signals from other terminal boards. Typical relays available for this model are solid-state relays and electromagnetic relays. Solid-state relays are used with TRLYH1B, C, D, and F terminals, while electromagnetic relays are used with TRLYH1E boards. This battery pack will receive input from a dual RJ45 Ethernet connector as well as a three-pin power input.

A processor board is embedded in the IS220PDOAH1A package. There are multiple processors, including but not limited to status indicating leds, local power supplies for monitoring and sorting, high-speed processors including flash and RAM memory, and more. All information about the processor can be found in the GEH-721G Mark VIe Control System Guide, information can be found on pages 223 to 230.

There is an output enable function for use with the IS220PDOAH1A package. In applications that power the battery pack, all outputs will be disabled until some internal self-testing is done. The enable function can provide a path independent of the command, which will ensure that the relay remains off during the initialization and power-on of the battery pack.
