PXIE-6738 PXI 模拟 输出 模 块 具非常适合各种应用
【产品详情】
National Instruments PXIe-6738 PXI 模拟 输出 模 块
National Instruments PXIe-6738 (部件号: 783800-01) 是一款 16 位、 32 通道、 1 MS/ s 高密度 模拟 输出 模 块。其模拟输出电压范围为-10 V至10 V。该小工具非常适合各种应用,例如震动反应测试和高密度的开圈娱乐。如果用户使用八个通道,每个直接通道位于不同的银行中,则可以实现最极端的检查率。
NI PXIe-6738 还 集成 了 10 个 数字 I/ O 线、 4 个 计数 器 / 时钟、 数字 触发 和 驱动 定 时, 可 满足 用户 的 各种 需求。PXI Express 的 数字 触发 和 同步 功能 使 该 模拟 输出 模 块 可以 补充 额外 的 数据 采集、 开发 和 视觉 项目, 从而 为 创意 测试 设计 提供 大幅 修改 的 估计 答案。在有限模式下,AO 启动触发器可配置为可重新触发。定时电机考虑AO启动触发信号上的每个脉冲,为设计的一代创建采样时钟。
在 PXIe 6738 中, 定时 电机 在 时钟 发生 器 提前 时 忽略 AO 启动 触发 信号。时钟发生器完成后,计数器等待另一个启动触发器开始另一个时钟生成。当用户创建模拟输出信号时,当声明中断触发时,生成将暂停。如果采样时钟的来源是板载时钟,则当延迟触发被遗弃时,生成将继续。该设备配备 1 个 68 针 VHDCI I/O 连接器。
PXIe-6738使用NIDAQmx驱动软件运行,该软件与LabVIEW、LabWindows/CVI或Measurement Studio等软件包/应用开发环境(ADE)兼容。它的建议预热时间为 15 分钟,应每年至少校准一次。
PXIE-6738 PXI 模拟 输出 模 块 具非常适合各种应用
【英文介绍】
National Instruments PXIe-6738 PXI analog output module
The National Instruments PXIe-6738 (Part number: 783800-01) is a 16-bit, 32-channel, 1 MS/ s high density analog output module. Its analog output voltage ranges from -10 V to 10 V. The gadget is ideal for a variety of applications, such as shock response testing and high-density open-loop entertainment. If a user uses eight channels, each direct channel located in a different bank, the most extreme check rate can be achieved.
The NI PXIe-6738 also integrates 10 digital I/ O lines, 4 counters/clocks, digital triggers and drive timing to meet a wide range of user needs. The PXI Express's digital triggering and synchronization capabilities enable the analog output module to complement additional data acquisition, development, and visual projects, providing substantially modified estimated answers for creative test designs. In limited mode, the AO start trigger can be configured to retrigger. The timing motor considers each pulse on the AO start trigger signal, creating a sampling clock for the designed generation.
In PXIe 6738, the timing motor ignores the AO start trigger signal when the clock generator is advanced. After the clock generator is complete, the counter waits for another start trigger to start another clock generation. When the user creates an analog output signal, the generation is paused when the declaration interrupt is triggered. If the source of the sampling clock is an onboard clock, the generation will continue when the delay trigger is abandoned. The device is equipped with a 68-pin VHDCI I/O connector.
The PXIe-6738 runs with NIDAQmx driver software, which is compatible with package/application development environments (ades) such as LabVIEW, LabWindows/CVI or Measurement Studio. It has a recommended warm-up time of 15 minutes and should be calibrated at least once a year.
