IS220PTURH1A Mark VI系统 用于燃气/蒸汽轮机管理

【产品详情】

IS220PTURH1A是GE为其Mark VI系统创建的组件。Mark VI 是 GE 发布的用于燃气/蒸汽轮机管理的最终 Speedtronic 系统之一。

IS220PTURH1A是主涡轮机专用主脱扣包。 该组件在涡轮机控制终端板与一个或两个以太网网络之间提供电气接口。该电池组的输出通过连接到相关端子板的 DC-62 引脚连接器进行。

IS220PTURH1A采用黑色外壳，带有空气流通开口。该外壳的正面有多个 LED 指示灯，以及一个 IR（红外端口）。此包中不使用此端口。在这个外壳内，有一个处理器板、一个专门用于涡轮机控制的第二块板和一个模拟采集辅助板。该电池组安装到TTURH1C端子板上。处理器板有两个 10/100 以太网端口、闪存和 RAM、一个用于识别的只读芯片、一个内部温度传感器和一个复位电路。

该IS220PTURH1A允许自动重新配置，自动从控制器下载到 I/O 包。重新配置包括基本负载、引导负载、固件和参数。必须启用自动重新配置才能执行此操作。这可以通过组件编辑器在 Toolbox ST 应用程序中启用或禁用。

IS220PTURH1A Mark VI系统 用于燃气/蒸汽轮机管理

【英文介绍】

The IS220PTURH1A is a component created by GE for its Mark VI system. The Mark VI is one of the final Speedtronic systems released by GE for gas/steam turbine management.

IS220PTURH1A is a special main trip package for the main turbine. This component provides an electrical interface between the turbine control terminal board and one or two Ethernet networks. The output of this battery pack is performed via a DC-62 pin connector connected to the relevant terminal board.

The IS220PTURH1A comes in a black housing with an air outlet. The front of the housing has multiple LED indicators, as well as an IR (infrared port). This port is not used in this package. Inside this enclosure, there is a processor board, a second board dedicated to turbine control, and an analog acquisition auxiliary board. The battery string is installed on the TTURH1C terminal board. The processor board has two 10/100 Ethernet ports, flash memory and RAM, a read-only chip for identification, an internal temperature sensor, and a reset circuit.

The IS220PTURH1A allows automatic reconfiguration and automatic download from the controller to the I/O package. Reconfiguration includes base load, boot load, firmware, and parameters. You must enable automatic reconfiguration to perform this operation. This can be enabled or disabled in the Toolbox ST application through the component editor.
