IS200TVBAH2A 振动输入端子板 用于单工或TMR应用

【产品详情】

IS200TVBAH2A功能描述

您可以将该组件用于单工或TMR应用。三个I/O包正在使用TMR应用程序传播信号。除了传统的37针连接外，TVBA还包含到附加连接器的缓冲输出。该功能使Bently Nevada 3500监控系统能够通过特定的9针和25针连接器供电。该特征还包括用于每个通道的卡口螺母连接(BNC)连接，以供给其他第三方监测装置。VIe/VIeS控制系统不使用Mark RKPS电源。

没有-28 V的外部电源；电源来自+28 V电源。

该模块具有三个可拆卸的子板，可将+28转换为-28。TVBA使用的所有负电源都来自这些WNPS(负电源)板。

IS200TVBAH2A安装

TVBA接受直接连接到两个I/O接线板的安装14传感器输入。每个接线板有24个端子，可以容纳高达#12 AWG的电线，并用两个螺钉固定。每个接线盒都靠近屏蔽终端连接点。

IS200TVBAH2A 振动输入端子板 用于单工或TMR应用

【英文介绍】

IS200TVBAH2A Function description

You can use this component for simplex or TMR applications. Three I/O packets are propagating signals using TMR applications. In addition to the traditional 37-pin connection, the TVBA also contains a buffered output to an additional connector. This feature enables the Bently Nevada 3500 monitoring system to be powered through specific 9-pin and 25-pin connectors. The feature also includes bayonet nut connections (BNC) for each channel to supply other third-party monitoring devices. VIe/VIeS control systems do not use Mark RKPS power supplies.

No external power supply of -28 V; Power supply from +28 V supply.

The module has three detachable daughter boards that convert +28 to -28. All negative power used by TVBA comes from these WNPS(negative power supply) boards.

IS200TVBAH2A is installed

TVBA accepts mounting 14 sensor inputs directly connected to two I/O patch panels. Each patch board has 24 terminals that can hold up to #12 AWG of wire and is secured with two screws. Each junction box is close to the shielded terminal connection point.
