IS200EPSMG2AEC 印刷电路板 数字信号处理器控制板
【产品详情】
该IS200DSPXH1CAA是 GE 制造的电路板 (PCB),作为其 Speedtronic Mark VI 系统的组件更换部件。 Mark VI 是 GE 的燃气轮机和蒸汽轮机控制系统之一,具体包括具有以太网功能的三重模块化冗余控制选项、CIMPLICITY 等专有软件和基于 Windows 的操作系统。
IS200DSPXH1CAA在Mark VI中用作数字信号处理器控制板。 该板有多个版本可用;请确保您订购的是适合您特定系统的正确版本。
该IS200DSPXH1CAA设计用于 Innovation 系列变频器以及 EX2100 励磁器。PCB 的数字信号处理器以 60 MHz 的频率运行。DSP可读的ASIC修订ID寄存器通常随电路板一起提供。这包括董事会的大部分专业和支持职能。板载固件存储在闪存中。
该IS200DSPXH1CAA采用直角背板连接器 (P1) 构建。它还有两个安装在其前面板上的连接器和一个位于这些连接器后面的附加垂直引脚连接器。该板有两个 LED 指示灯安装在面板上。有 16 个集成电路、电阻器、电阻器网络阵列、晶体管、二极管和电容器。该板已在工厂钻孔。
IS200EPSMG2AEC 印刷电路板 数字信号处理器控制板
【英文介绍】
The IS200DSPXH1CAA is a circuit board (PCB) manufactured by GE as a component replacement part for its Speedtronic Mark VI system. The Mark VI is one of GE's gas turbine and steam turbine control systems that includes triple modular redundancy control options with Ethernet capabilities, proprietary software such as CIMPLICITY, and Windows-based operating systems.
The IS200DSPXH1CAA is used as a digital signal processor control board in Mark VI. Multiple versions of the board are available; Make sure you order the correct version for your specific system.
The IS200DSPXH1CAA is designed for use with the Innovation series inverter and EX2100 exciter. The PCB's digital signal processor runs at 60 MHz. A DSP-readable ASIC revision ID register is usually supplied with the board. This includes most of the professional and support functions of the Board. The onboard firmware is stored in flash memory.
The IS200DSPXH1CAA is built with a right Angle backplane connector (P1). It also has two connectors mounted on its front panel and an additional vertical pin connector located behind these connectors. The board has two LED indicators mounted on the panel. There are 16 integrated circuits, resistors, resistor network arrays, transistors, diodes, and capacitors. The board has been drilled in the factory.
