IC693MDL240G 离散输入模块 通用输入模块

【产品详情】

品牌 GE发那科

系列 90-30系列

制造者 GE发那科

产品描述 离散输入模块

零件编号 IC693MDL240

通道数 十六 （16）

IC930MDL240是 90-30 系列产品系列中的分立式输入模块。该模块以前由 GE Fanuc Automation 制造，但最近被 Emerson Automation 收购。该模块为通用输入模块，占用CPU、I/O扩展或远程I/O底板的单个I/O插槽。

该IC930MDL240在 0-132 VAC 的输入电压范围内工作，频率为 50/60 Hz，而标称电压为 120 VAC，标称输入电流为 12 mA。该模块可用于检测二进制操作现场设备（如开关、按钮、辅助触点和其他类似操作设备）的状态变化。

该IC930MDL240带有一组输入通道，现场侧和逻辑侧之间的隔离额定值为 1500 VAC （rms）。它的导通状态电压范围为 74-132 VAC，导通状态电流为 6 mA，而关闭状态电压为 0-20 VAC，关闭状态电流为 2.2 mA。每个通道的最大导通响应时间为 30 ms，最大关断响应时间为 45 ms。该模块的电流消耗为 90 mA @ 5VDC 总线电压。

IC930MDL240的安装数量没有限制。根据系统需要安装任意数量的设备。唯一的限制是主机控制器的 I/O 容量及其支持的扩展或远程 I/O 底板的数量。

根据固件版本或主机控制器的版本，用于配置IC930MDL240的编程软件会有所不同。可用于将此模块参数化为 LogicMaster 90-30、VersaPro 或 Proficy Machine Edition 软件包的软件包。

GE Fanuc IC693MDL240输入模块是 90-30 GE PLC 系列产品线的一部分。它的额定电压为 120 伏交流电，16 个输入点共享一个公共电源输出端子。这 16 个电路包括一个电容器和一个电阻器，它们是电抗输入。当电流通过输入点时，输入状态表中的逻辑读数为逻辑 1 （%I）。它具有与各种输入设备兼容的功能输入模块。例如，操作员可以将其与限位按钮、开关或电子接近开关一起使用。GE Fanuc IC693MDL240模块可以与现场设备一起使用，当用户提供电源来支持它们时。

IC693MDL240模块需要交流电源，因为它不能使用直流电运行。该模块顶部有 LED 指示灯，用于显示每个输入点的 ON 和 OFF 状态。该模块还有 2 排水平 LED，每排有 8 个绿色 LED。第一排 LED 标记为输出点 1 至 8 的 A1 至 A8，底行标记为 B1 至 B8 的输出点 9 至 16。IC693MDL240输入模块具有铰链门。在模块的内门表面和外门表面之间还有一个插入物。当这扇门关闭时，内表面有关于电路接线的信息。内表面记录电路标识信息。该模块是 GE 90-30 系列可编程逻辑控制器系统的重要补充，用户可以将其安装在任何 5 插槽或 10 插槽 I/O 基板上。

IC693MDL240G 离散输入模块 通用输入模块

【英文介绍】

Brand GE Fanuc

Series 90-30 series

Manufacturer GE Fanuc

Product description Discrete input module

Part number IC693MDL240

Number of channels 16 (16)

The IC930MDL240 is a discrete input module in the 90-30 series product family. The module was previously manufactured by GE Fanuc Automation, but was recently acquired by Emerson Automation. This module is a universal input module that occupies a single I/O slot on the CPU, I/O expansion, or remote I/O baseboard.

The IC930MDL240 operates in an input voltage range of 0-132 VAC with a frequency of 50/60 Hz, while the nominal voltage is 120 VAC and the nominal input current is 12 mA. The module can be used to detect state changes in binary operating field devices such as switches, buttons, auxiliary contacts, and other similar operating devices.

The IC930MDL240 comes with a set of input channels and is rated 1500 VAC (rms) for isolation between the field side and the logical side. It has an on-state voltage range of 74-132 VAC and an on-state current of 6 mA, while a off state voltage of 0-20 VAC and a off state current of 2.2 mA. The maximum on-off response time for each channel is 30 ms and the maximum turn-off response time is 45 ms. The current consumption of the module is 90 mA @ 5VDC bus voltage.

There is no limit to the number of IC930MDL240 installations. Install as many devices as needed. The only limitation is the I/O capacity of the host controller and the number of extended or remote I/O backboards it supports.

The programming software used to configure the IC930MDL240 varies depending on the firmware version or the version of the host controller. A package that can be used to parameterize this module to the LogicMaster 90-30, VersaPro, or Proficy Machine Edition packages.

The GE Fanuc IC693MDL240 input module is part of the 90-30 GE PLC series product line. It has a rated voltage of 120 volts AC, and 16 input points share a common power output terminal. These 16 circuits include a capacitor and a resistor, which are reactance inputs. When the current passes through the input point, the logic reading in the input status table is logic 1 (%I). It has functional input modules that are compatible with various input devices. For example, operators can use it with a limit button, switch, or electronic proximity switch. The GE Fanuc IC693MDL240 module can be used with field devices when the user provides power to support them.

The IC693MDL240 module requires AC power because it cannot operate on direct current. The module has LED indicators at the top to show the ON and OFF status of each input point. The module also has 2 rows of horizontal leds, each with 8 green leds. The first row of leds is labeled A1 to A8 from output points 1 to 8, and the bottom row is labeled output points 9 to 16 from B1 to B8. The IC693MDL240 input module has hinged doors. There is also an insert between the inner door surface and the outer door surface of the module. When this door is closed, the inside surface has information about the wiring of the circuit. The inner surface records circuit identification information. The module is an important addition to GE's 90-30 series programmable logic controller system and can be installed on any 5-slot or 10-slot I/O substrate.

IC693MDL240G 离散输入模块 通用输入模块
