DS200DCFBG1BLC是通用电气公司为Mark V系列可选板和替换板设计的电源板。该系列的成员与许多GE品牌的激励器和驱动器交叉兼容。来自DC2000. AC2000. CB2000、 ME2000和FC2000的驱动器都可以接受这个电源板。 此卡为其安装的驱动器提供系统控制级电源，井为机柜风扇供电。有出处的交流输入到此板可以评级从38至115伏交流电压。伴随这种真空的频率范围可以从0至500千赫取决于输入电压的强度。

GE DS200DCFBG1BLC 电源版

DS20DCFBG1BLC包含许多复杂的电路系统，旨在为大部分驱动器供电。该卡包括交流和DC监控电路、控制电平供电电路、电机磁场电源电路和驱动电路。用户可以配置十二个跳线和七个DIP开关以满足任何外部要求。主板状态通过板载指示器传达给用户。该卡内置两个LED和一个霓虹灯指示器，为用户提供重要的诊断和状态信息。电路板的三个保险丝受到保护，确保中断或浪涌不会中断电流。务必使用定期监控电压电平五个测试点集成到电路板中。

必须遵循DS200DCFBG1BLC和变频器提供的安装参数。这些指南将确保主板及其安装的系统按预期运行。有关接线和安装指南，请参考系列手册和设备数据表。Mark V系列中所有主板的技术支持最初由制造商通用电气公司提供。

GE DS200DCFBG1BLC Power supply version

The DS200DCFBG1BLC is a power board designed by General Electric for the Mark V Series optional and replacement boards. Members of the family are cross-compatible with many GE branded exciters and drives. Drives from DC2000.AC2000.CB2000, ME2000, and FC2000 can accept this power strip. The card provides system control level power to the driver it is mounted on, and the well supplies power to the cabinet fan. The AC input to this board can be rated from 38 to 115 volts AC. The frequency accompanying this vacuum can range from 0 to 500 KHZ depending on the strength of the input voltage.

GE DS200DCFBG1BLC Power supply version

The DS20DCFBG1BLC contains a number of complex circuit systems designed to power most of the drivers. The card includes an AC and DC monitoring circuit, a control level power supply circuit, a motor magnetic field power supply circuit and a drive circuit. The user can configure twelve jumpers and seven DIP switches to meet any external requirements. The status of the motherboard is communicated to the user via onboard indicators. The card has two built-in leds and a neon indicator to provide users with important diagnostic and status information. The board's three fuses are protected to ensure that interruptions or surges do not interrupt the current. Be sure to use five test points to regularly monitor voltage levels integrated into the board.

Installation parameters provided by DS200DCFBG1BLC and inverter must be followed. These guidelines will ensure that the motherboard and the system it is installed on perform as intended. Refer to the series manuals and equipment data sheets for wiring and installation instructions. Technical support for all motherboards in the Mark V series was initially provided by manufacturer General Electric.
