GE IS230TCISH6C Mark VIe 系列 DIN 导轨 I/O 模块

【产品详情】

IS230TCISH6C是由General Electric制造和设计的DIN导轨I/O模块。它是GE分布式控制系统中使用的Mark VIe系列的一部分。Mark VIe I/O模块用于涡轮机和电厂控制系统。它的I/O模块反映了这种多样性，具有多种类型，并且能够单独或集群分布它们。I/O模块由安装在端子板上的I/O包组成。I/O包包括一个运行QNX操作系统的本地处理器以及一个数据采集板。接线板包括现场接线端子块和将端子块连接到I/O包的无源电路。万一模块的无源电路发生故障，可以拆除接线端子并连接现场接线。

特征

IS230TCISH6C用作I/O端子板。该板由两个接线盒组成，每个接线盒都有两排螺钉连接。这些块在卡的一个长边上排成一行安装到板上。每个块由两个螺钉固定在一起。

IS230TCISH6C的另一侧有三个37针(母)连接器。模块上还有两个插头连接器。该板安装在与DIN导轨兼容的金属载体中。出厂预留的孔中有两个是SCOM(接地)的机箱接地螺丝，接法要尽可能短。

I/O模块特性

I/O模块由安装在端子板上的I/O包组成。I/O包包括一个运行QNX操作系统的本地处理器以及一个数据采集板。接线板包括现场接线端子块和将端子块连接到I/O包的无源电路。

万一模块的无源电路发生故障，可以拆除接线端子并连接现场接线。包含两个栅栏式、可插拔接线端子，每个接线端子有24个点。使用环形接线片，每个点可以接受两根2.05 mm2(0.081 in2)#12 AWG电线，绝缘电压为300 V。还提供了用于端接裸线的固定夹。

螺钉中心间距为9.53毫米(0.375英寸)。T型模块通常安装在底座上，可以容纳多个I/O包。S型模块上的盒式接线端子可接受一根2.05 mm2(0.081 in2)#12 AWG电线或两根1.63 mm2(0.064 in2)#14 AWG电线，每点绝缘300 V。螺钉中心间距为5.08毫米(0.2英寸)。S型模块采用DIN导轨和底座安装，带有单个I/O包。

IS220PAICH1A MKVIe，模拟输入/输出基本包(10进，2出)

IS220PAICH1B IO包,模拟在/基本BPPC

IS220PAICH1BAX IO包,模拟/基本,HAZLOC

IS220PAICH2A MKVIe，模拟输入/输出包(200mA)

IS220PAICH2B IO包，模拟输入/输出，0-200mA,BPPC

IS220PAOCH1A模拟IO PACKT基本

IS220PAOCH1B IO包,模拟,BPPC

IS220PAOCH1BAX IO包,模拟,HAZLOC

IS220PCLAH1A MKVIe，核心模拟包，BPPB，用于航空单位

BPPC IS220PCLAH1B IO包,航空核心模拟

IS220PCNOH1A MKVIe CANOPEN接口包

BPPC IS220PCNOH1B IO包,CANOPEN主网关

GE IS230TCISH6C Mark VIe 系列 DIN 导轨 I/O 模块

【英文介绍】

The IS230TCISH6C is a DIN rail I/O module manufactured and designed by General Electric. It is part of the Mark VIe family used in GE's distributed control systems. Mark VIe I/O modules are used in turbine and power plant control systems. Its I/O modules reflect this diversity, with multiple types and the ability to distribute them individually or in clusters. The I/O module consists of an I/O package installed on the terminal board. The I/O package includes a local processor running the QNX operating system and a data acquisition board. The patch board includes a field terminal block and a passive circuit connecting the terminal block to the I/O packet. In case the passive circuit of the module fails, you can remove the terminal and connect the field cable.

trait

IS230TCISH6C is used as an I/O terminal board. The board consists of two junction boxes, each of which is connected by two rows of screws. The blocks are mounted in a row on one long side of the card to the board. Each block is held together by two screws.

The IS230TCISH6C has three 37-pin (female) connectors on the other side. There are also two plug connectors on the module. The board is mounted in a metal carrier compatible with DIN rail. Two of the holes reserved by the factory are SCOM(grounding) chassis grounding screws, and the connection should be as short as possible.

I/O module features

The I/O module consists of an I/O package installed on the terminal board. The I/O package includes a local processor running the QNX operating system and a data acquisition board. The patch board includes a field terminal block and a passive circuit connecting the terminal block to the I/O packet.

In case the passive circuit of the module fails, you can remove the terminal and connect the field cable. Contains two palisade, pluggable terminals, each with 24 points. Using a ring connector, each point can accept two 2.05 mm2(0.081 in2)#12 AWG wires with an insulation voltage of 300 V. A retaining clamp for terminating bare wires is also provided.

The screw center spacing is 9.53 mm (0.375 in). T-modules are usually mounted on a base and can accommodate multiple I/O packages. The box terminals on the Model S module can accept one 2.05 mm2(0.081 in2)#12 AWG wire or two 1.63 mm2(0.064 in2)#14 AWG wires with 300 V insulation at each point. The screw center spacing is 5.08 mm (0.2 in). Model S modules are DIN rail and base mounted with a single I/O package.

IS220PAICH1A MKVIe, analog input/output basic package (10 in, 2 out)

IS220PAICH1B IO package, simulated in/basic BPPC

IS220PAICH1BAX IO package, Analog/Basic,HAZLOC

IS220PAICH2A MKVIe, Analog Input/Output Package (200mA)

IS220PAICH2B IO package, analog input/output, 0-200mA,BPPC

The IS220PAOCH1A simulates IO PACKT

IS220PAOCH1B IO package, emulation,BPPC

IS220PAOCH1BAX IO package, simulation,HAZLOC

IS220PCLAH1A MKVIe, Core simulation package, BPPB, for aviation units

BPPC IS220PCLAH1B IO package, Aviation core simulation

IS220PCNOH1A MKVIe CANOPEN interface packet

BPPC IS220PCNOH1B I/O packet, the main gateway of CANOPEN
