GE VMIVME-M-485 长线中继器链路模块

【产品详情】

特征：

单宽 VMEbus 模块

用于长线中继器的主中继器模块

DIN 型 I/O 连接器

双 Eurocard 外形尺寸

支持 16 位和 24 位寻址

支持 8 位和 16 位数据传输

GE Fanuc / VMIC VMIVME-Repeat L-485 长线中继器链路模块是 VMIC 长线中继器链路中的两种板卡型号之一。VMIC长线中继器链路由两块板组成。一块板被命名为 VMIVME-Repeat M-485，而另一块板被命名为 VMIVME-Repeat S-485。这两个板之所以被称为 VMEbus 机箱，是因为它们与主 VMEbus 机箱和从机箱相关联。

VMIVME-Repeat M-485 板在主 VMEbus 机箱中显示为 VMEbus 从属板。VMIVME-Repeat M-485 的地址空间是驻留在 VMEbus 从机箱中的每个从属板的组合地址空间。

该模块是VMIC设备系列的一部分，最初由通用电气的工业自动化生产部门设计、制造和批量生产。然而，后来该系列被 Abaco Systems 收购并生产。

此型号列出了 VMIVME-M-485，一种重复 L-485 长线中继器链路模块。该装置具有一系列独特的功能，例如单个宽 VME 总线连接端口、用于该装置长线路中继器的主中继器模块，以及一组 DIN 型输入和输出连接器。

VMIVME-M-485 模块设计为 VMIC 长线路中继器链路子系列产品中的两个单元之一。这些模型由两块板组成：一组是 VMIVME-Repeat-S-485 型号，另一组是这块板。这些板卡串联在一起，因为它们与主 VMEbus 机箱相关联，因此被称为 VMEbus 机箱。

VMIVME-M-485 单元还设计用于容纳双 Eurocard 外形模块，并能够支持 16 位和 24 位寻址，以及 8 位和 16 位数据传输。

它完全能够支持所有七个可用的中断级别。连接了 400 英尺长的电缆，传播延迟约为 5 纳秒。对于连接的较长电缆，每英尺有额外的 4 纳秒。

GE VMIVME-M-485 长线中继器链路模块

【英文介绍】

Features:

Single-width VMEbus module

Main repeater module for long line repeater

DIN type I/O connector

Double Eurocard form factor

Supports 16-bit and 24-bit addressing

Supports 8-bit and 16-bit data transmission

GE Fanuc/VMIC VMIVME-Repeat L-485 Long Line repeater link module is one of the two board models in the VMIC long line repeater link. The VMIC long line repeater link consists of two boards. One board is named VMIVME-Repeat M-485, while the other board is named VMIVME-Repeat S-485. These two boards are called VMEbus chassis because they are associated with the main VMEbus chassis and the slave chassis.

The VMIVME-Repeat M-485 board is displayed as a VMEbus slave board in the active VMEbus chassis. The address space of the VMIVME-Repeat M-485 is the combined address space of each slave board residing in the VMEbus slave chassis.

The module is part of a family of VMIC devices originally designed, manufactured and mass-produced by GE's Industrial Automation production division. However, the series was later acquired and produced by Abaco Systems.

This model lists the VMIVME-M-485, a repetitive L-485 long line repeater link module. The unit has a range of unique features, such as a single wide VME bus connection port, a master repeater module for the unit's long line repeater, and a set of DIN type input and output connectors.

The VMIVME-M-485 module is designed as one of two units in the VMIC Long Line Repeater link subfamily. These models consist of two plates: one for the VMIVME-Repeat-S-485 model and the other for this plate. These boards are connected in series, and because they are associated with the main VMEbus chassis, they are called VMEbus chassis.

The VMIVME-M-485 unit is also designed to accommodate dual Eurocard form factor modules and is capable of supporting 16-bit and 24-bit addressing, as well as 8-bit and 16-bit data transmission.

It fully supports all seven available interrupt levels. A 400-foot cable was connected, with a propagation delay of about 5 nanoseconds. For longer cables connected, there is an additional 4 nanoseconds per foot.
