VMIVME-3113A 数转换器模块 带内置测试
【产品详情】
VMIVME-3113A-100
• 输入滤波器:40 Hz 滤波器(3 dB 截止频率)
部件号 332-103113-100
产品代码: 5998-01-386-1229, 5998013861229, 5998-01-594-3343, 5998015943343
特征:
64 个差分或单端输入
跳线可选扫描 2 至 64 个通道
五种操作模式和测试模式
为专用通道双端口寄存器提供 8 位连续数字化
GE Fanuc / VMIVME-3113A 设计用于支持 64 通道差分或单端宽范围(+/-10mV 至 +/-10V)模拟输入。64字双端口为连续扫描所有通道提供存储。扫描模式在上电、系统复位或在程序控制下自动执行。双端口寄存器允许 VMEbus 随时访问以读取最新存储的数据。跳线可选的可编程增益放大器支持1、10、100、200和500的增益范围。A/D转换时间为15μs。支持多种低通滤波器。
VMIC系列设备是一系列电路板,设计有几种不同的功能:例如模数转换器(反之亦然)、中央处理模块以及模拟和数字输入和输出模块。这些设备均由通用电气的工业自动化生产部门开发、设计和制造。VMIC 板可从 AX Control 获得,作为二手但翻新的材料。这些设备中的每一个都包含在我们全面的保护性保修协议中。
VMIVME-3113A 模块是一款模数转换器,能够支持多达 64 个差分和/或单端宽范围模拟输入通道(正负 10 mV 至正负 10 V)。
VMIVME-3113A 模块集成了一个 64 字双端口,能够为设备所有通道的连续扫描提供存储。不同的扫描模式在通电、系统复位或在程序控制下手动输入时自动启用。双端口寄存器允许 VMEbus 随时访问,以便操作员能够读取最新存储的数据。该单元的跳线可选可编程增益放大器能够支持 1、10、100、200 和高达 500 的增益范围。VMIVME-3113A 的模数转换时间为 15 μs。
VMIVME-3113A 数转换器模块 带内置测试
【英文介绍】
VMIVME-3113A-100
• Input filter: 40 Hz filter (3 dB cutoff frequency)
Part number 332-103113-100
Product code: 5998-01-386-1229, 5998013861229, 5998-01-594-3343, 5998015943343
Features:
64 differential or single-ended inputs
The jumper can optionally scan 2 to 64 channels
Five operating modes and test modes
8-bit continuous digitizing for dedicated channel dual-port registers
The GE Fanuc/VMIVME-3113A is designed to support 64-channel differential or single-ended wide-range (+/-10mV to +/-10V) analog inputs. 64-word dual ports provide storage for continuous scanning of all channels. Scan mode is performed automatically on power-on, system reset, or under program control. The dual-port register allows the VMEbus to access it at any time to read the latest stored data. Jumper Optional programmable gain amplifiers support gain ranges of 1, 10, 100, 200 and 500. The A/D conversion time is 15μs. Supports a variety of low-pass filters.
VMIC series devices are a series of circuit boards designed with several different functions: for example, analog-to-digital converters (and vice versa), central processing modules, and analog and digital input and output modules. The devices were developed, designed and manufactured by GE's Industrial Automation production division. VMIC boards are available from AX Control as used but refurbished materials. Each of these devices is included in our comprehensive protective warranty agreement.
The VMIVME-3113A module is an analog-to-digital converter capable of supporting up to 64 differential and/or single-ended wide-range analog input channels (plus-minus 10 mV to plus-minus 10 V).
The VMIVME-3113A module integrates a 64-word dual port that provides storage for continuous scanning of all channels of the device. Different scanning modes are automatically enabled when powered on, the system is reset, or manually entered under program control. The dual-port register allows the VMEbus to be accessed at any time so that the operator can read the latest stored data. The unit's jumper optional programmable gain amplifier is capable of supporting gain ranges of 1, 10, 100, 200 and up to 500. The analog-to-digital conversion time of the VMIVME-3113A is 15 μs.
