VMIVME-3112 模数转换器模块 具有多种操作模式

【产品详情】

VMIVME-3112-000 • 输入滤波器：无

• 输入：64 个差分/单端模拟输入通道

特征：

可编程间隔定时器

可编程增益放大器

多种操作模式

VMIVME-3112 扫描 12 位模数转换器模块具有多种操作模式，包括自动扫描、随机轮询、扫描轮询和扫描中断。它还具有可编程间隔定时器、外部触发、可编程增益放大器和转换结束/扫描中断。

该转换器模块最初由通用电气的 Fanuc Automation 部门开发。然而，它随后被从通用电气的大规模生产线上移除，并被 Abaco Systems 作为这些装置的主要生产商。

特别是 VMIVME-3112 型号是一个模数转换器单元或 ADC。在生产时，它被认为是可用的领先产品之一，也是工业设备市场上密度最高/每通道板成本最低的产品之一。

VMIVME-3112 模块设计用于容纳众多特性和功能，例如通电时自动启用的自动扫描模式，以及所有输入的模数转换。然后，转换后的数据存储在专用通道双端口寄存器中。这使得该装置无需任何编程即可正常运行。

VMIVME-3112 模块设计有多达 64 个单端和差分输入。本机还有五种操作模式：自动扫描模式、随机轮询模式、随机中断模式、扫描轮询模式和扫描中断模式。可以一次对 2 到 64 个通道进行跳线选择扫描。

VMEbus 附件能够在完成单个模数转换或完成 16 到 64 通道扫描时中断。

VMIVME-3112 模数转换器模块 具有多种操作模式

【英文介绍】

VMIVME-3112-000 • Input filter: None

• Input: 64 differential/single-ended analog input channels

Features:

Programmable interval timer

Programmable gain amplifier

Multiple operating modes

The VMIVME-3112 Scan 12-bit analog-to-digital converter module has several modes of operation, including automatic scan, random polling, scan polling and scan interrupt. It also features programmable interval timers, external triggers, programmable gain amplifiers, and end of conversion/scan interrupts.

The converter module was originally developed by General Electric's Fanuc Automation division. However, it was subsequently removed from General Electric's mass production line and adopted by Abaco Systems as the main producer of these units.

In particular, the VMIVME-3112 model is an analog-to-digital converter unit or ADC. At the time of production, it was considered one of the leading products available and one of the highest density/lowest cost per channel plate in the industrial equipment market.

The VMIVME-3112 module is designed to accommodate numerous features and functions, such as the automatic scanning mode that is automatically enabled when powered on, and the analog-to-digital conversion of all inputs. The converted data is then stored in a dedicated channel dual-port register. This allows the device to function without any programming.

The VMIVME-3112 module is designed with up to 64 single-ended and differential inputs. The machine also has five modes of operation: automatic scan mode, random polling mode, random interrupt mode, scan polling mode, and Scan interrupt mode. The jumper selection scan can be performed on 2 to 64 channels at a time.

The VMEbus attachment is capable of interrupting when completing a single analog-to-digital conversion or when completing a 16 to 64 channel scan.
