VMIVME-2534 位数字 I/O 板 具有四个端口
【产品详情】
概述
特征:
32位高压输出和/或输入
每组 8 路输入可通过跳线选择进行监控
P2 I/O 连接
带故障 LED 的前面板
VMIC / GE Fanuc-2534 32 位 I/O 板具有四个端口,可在 8 位、16 位或 32 位边界上单独寻址。用于控制和状态寄存器 (CSR) 和电路板 ID 寄存器的单独电路板地址解码器允许对硬件控制地址进行分组,以提高软件效率。地址修饰符代码可通过跳线选择,用于短监控或短时非特权 I/O 访问。
输入可通过跳线选择,用于监控:触点闭合、电压源、电流吸收和差分信号。开路提供逻辑“零”或(跳线可选)逻辑“一”。VMIVME-2534 还具有输入滤波器选项和用户可选的输入电压阈值。
输出具有高电流吸收 (600 mA)、高击穿电压 (70 V)、输出箝位二极管和用于减少电流浪涌的保持活动电路。
通用电气工业自动化部门的VMIC系列设备。这些器件包括模数转换器板、CPU 模块、输入和输出板等产品。这些模块最初都是GE的产品,但是,它们被撤出生产,后来被Abaco Systems收购。
本机被指定为高压数字输入和输出板的 VMIVME-2534 型号。该装置设计有 32 位高压输出,并具有 600 毫安的高电流吸收器。此外,还有较高的击穿电压,直流电至少为 60 伏。
VMIVME-2534 模块还配备了一系列输出钳位二极管,并配备了 1 安培过流保护功能,并具有热限制保护功能。VMIVME-2534 配有一个UDN2549B型负载驱动器,该驱动器是白炽灯和电感式的。
VMIVME-2534 单元的 32 位高压输入分为 8 个输入,并且完全可通过跳线选择进行监控。开路能够提供逻辑零点,或跳线可选逻辑零点。该装置中集成了用于这些输入的滤波器选件。这些输入的用户可选电压阈值范围为低至 1.25 至 60 V。
