STXDNS925 具有16个源输入和8个继电器输出

【产品详情】

RSTi DeviceNet，内置 16 个 24VDC 电源（负逻辑）输入和 8 个隔离继电器输出，可扩展至 10 个附加模块。

STXDNS925模块是GE Fanuc制造的DeviceNet模块，具有16个源输入和8个继电器输出，额定电压为24伏直流。使用STXDNS10 DeviceNet模块可以进一步扩展到多达924个附加模块。DeviceNet网络是一种低级网络，通过同一本地网络在工业设备（执行器、控制器和传感器）之间提供连接。它将控制信息传输到不同的低级设备或从不同的低级设备传输控制信息。DeviceNet网络遵循通用的行业协议，支持主从和点对点通信。从设备可以STXDNS925模块有一个开放式外壳，前面板上有一个连接端口和 LED 指示灯。LED 指示灯是“Field Power”、“MOD”、“NET”和“I/O”LED。当网络模块通电时，“现场电源”指示灯开始闪烁。当网络激活过程正在进行时，“NET”LED 会亮起。模块中的节点地址可以通过使用位于模块底部 DIN 导轨上方的刻度盘来更改。网络模块支持不同的波特率。波特率的设置是可变的。DeviceNet 模块使用带有 5 针连接器的专用电缆。数据传输以 125、250 和 500 Kbps 的不同通信速度完成。该STXDNS924支持 2016 个数字 I/O 点和 126 个模拟 I/O 点。DeviceNet 模块支持的不同工作模式包括 COS、Polling、Cycling 和 Bit 选通。模块的现场电源电流为 10 安培，FnBus 电源电流为 1.2 安培，直流电压为 5 伏。

STXDNS925 具有16个源输入和8个继电器输出

【英文介绍】

RSTi DeviceNet with 16 built-in 24VDC power (negative logic) inputs and 8 isolated relay outputs, expandable to 10 additional modules.

The STXDNS925 module is a DeviceNet module manufactured by GE Fanuc with 16 source inputs and 8 relay outputs rated at 24 volts DC. The STXDNS10 DeviceNet module can be further expanded to up to 924 additional modules. A DeviceNet network is a low-level network that provides connectivity between industrial devices (actuators, controllers, and sensors) through the same local network. It transmits control information to or from different low-level devices. The DeviceNet network follows common industry protocols and supports both master-slave and point-to-point communication. The STXDNS925 module has an open housing with a connection port and LED indicator on the front panel. The LED indicators are "Field Power", "MOD", "NET" and "I/O" leds. When the network module is powered on, the Field Power indicator starts to blink. When the network activation process is in progress, the "NET" LED lights up. The node address in the module can be changed by using a dial located above the DIN rail at the bottom of the module. Network modules support different baud rates. The baud rate setting is variable. The DeviceNet module uses a dedicated cable with a 5-pin connector. Data transfer is done at different communication speeds of 125, 250 and 500 Kbps. The STXDNS924 supports 2016 digital I/O points and 126 analog I/O points. The DeviceNet module supports different working modes including COS, Polling, Cycling, and Bit strobe. The module's field power supply current is 10 amps, the FnBus power supply current is 1.2 amps, and the DC voltage is 5 volts.
