STXDNS825 带有集成 I/O 连接测试点

【产品详情】

STXDNS825适配器模块是GE Fanuc制造的DeviceNet适配器。它带有集成 I/O，包括 16 个灌电流输入和 8 个继电器输出，即 24 伏直流隔离继电器输出。它有一个开放式外壳，应安装在污染等级为 2 级工业环境的外壳内。正面有 4 个不同的 LED 指示灯，分别是“MOD”、“NET”、“I/O”和“Field Power”LED。前面板上还有一个用于切换节点地址的旋转拨盘。旋转拨盘可以切换 x10 和 x1 地址。STXDNS825适配器模块有一个连接测试点，可用于手动测试模块的功能。一个简单的推弹簧夹端子用于连接14 AWG规格的电线。DeviceNet 模块可以使用位于设备底部的 DIN 导轨进行安装。

STXDNS825适配器模块在正常工作条件下以 30 伏直流电压消耗总共 24 毫安的电流。DeviceNet 模块上提供不同的操作模式，包括位选通、轮询、cOS 和循环模式。这些模式中的每一种都有自己的功能。该模块最多支持 64 个附加节点。最大数字 I/O 计数为 2016 个点，最大模拟 I/O 计数为 216 个通道。它一次最多支持 252 字节的数据。RSTi模块的分布式特性有助于减少拆卸时间，从而减少机器的调试。可以使用在 Microsoft Windows 操作系统上运行的 Proficy Machine Edition 软件来配置 STXDNS825 适配器模块。

STXDNS825 带有集成 I/O 连接测试点

【英文介绍】

The STXDNS825 adapter module is a DeviceNet adapter manufactured by GE Fanuc. It comes with integrated I/O, consisting of 16 perfusion current inputs and 8 relay outputs, i.e. 24 volt DC isolated relay outputs. It has an open housing and should be installed in a housing with a pollution class 2 industrial environment. There are 4 different LED indicators on the front, which are "MOD", "NET", "I/O" and "Field Power" leds. There is also a rotary dial on the front panel for switching node addresses. The rotary dial can switch between x10 and x1 addresses. The STXDNS825 adapter module has a connection test point that can be used to manually test the module's functionality. A simple push-spring clamp terminal is used to connect 14 AWG gauge wires. The DeviceNet module can be mounted using the DIN rail located at the bottom of the device.

The STXDNS825 adapter module consumes a total of 24 mA of current at 30 volts DC under normal operating conditions. Different modes of operation are available on the DeviceNet module, including bit-strobe, polling, cOS, and loop modes. Each of these patterns has its own function. The module supports up to 64 additional nodes. The maximum digital I/O count is 2016 points and the maximum analog I/O count is 216 channels. It supports up to 252 bytes of data at a time. The distributed nature of the RSTi module helps to reduce the disassembly time and thus the debugging of the machine. The STXDNS825 adapter module can be configured using Proficy Machine Edition software running on Microsoft Windows operating systems.

STXDNS825 带有集成 I/O 连接测试点
