STXDNS824 RSTi DeviceNet模块 工业通信协议

【产品详情】

STXDNS824模块是一个RSTi DeviceNet模块，具有16个灌电流输入和8个继电器输出。输入和输出都是内置的，并且可以通过多达 10 个附加模块进行扩展。该模块用于与本地工业网络中的设备进行通信。DeviceNet协议是一种工业通信协议。如果需要，可以轻松配置和升级。该模块带有基于以太网的 I/O 和高速通信模块，可提高工业自动化过程的灵活性和可靠性。STXDNS824模块体积小，尺寸为 42 x 99 x 70 毫米。它重约 155 克。它符合工业和环境标准，包括 UL、cUL、CE 和 ODVA 标准。安装区域的温度应保持在-20至50摄氏度之间。

STXDNS824 RSTi模块提供模块电源智能模块和现场电源智能模块以及可相互使用的通信智能模块。这些智能模块配备了诊断功能，可帮助设备检测操作过程中的错误。STXDNS824 模块使用 5 伏直流母线将电源从一个模块传递到另一个模块。DeviceNet模块可以通过使用Proficy Machine Edition软件轻松配置和控制。该模块可以连接到带有串行端口的个人计算机。STXDNS824模块带有内置模块锁定机制，可将其牢固地固定在DIN导轨上。模块正面有可拆卸的接线端子，便于安装和更换。使用专用 Devicenet 电缆时，DeviceNet 模块支持 125、250 和 500 Kbps 的不同通信速度。

STXDNS824 RSTi DeviceNet模块 工业通信协议

【英文介绍】

The STXDNS824 module is an RSTi DeviceNet module with 16 perfusion current inputs and 8 relay outputs. Both inputs and outputs are built in and can be extended with up to 10 additional modules. This module is used to communicate with devices in the local industrial network. DeviceNet protocol is an industrial communication protocol. It can be easily configured and upgraded if needed. The module comes with Ethernet-based I/O and high-speed communication modules to improve the flexibility and reliability of industrial automation processes. The STXDNS824 module is small in size, measuring 42 x 99 x 70 mm. It weighs about 155 grams. It complies with industrial and environmental standards, including UL, cUL, CE and ODVA standards. The temperature of the installation area should be maintained between -20 and 50 degrees Celsius.

The STXDNS824 RSTi module provides the module power intelligent module and the field power intelligent module as well as the interoperable communication intelligent module. These smart modules are equipped with diagnostic functions to help the device detect errors during operation. The STXDNS824 module uses a 5-volt DC bus to transfer power from one module to another. The DeviceNet module can be easily configured and controlled using Proficy Machine Edition software. The module can be connected to a personal computer with a serial port. The STXDNS824 module comes with a built-in module locking mechanism to secure it firmly to the DIN rail. The front of the module has removable terminals for easy installation and replacement. When using dedicated Devicenet cables, DeviceNet modules support different communication speeds of 125, 250, and 500 Kbps.

STXDNS824 RSTi DeviceNet模块 工业通信协议
