IC200MDD845 组合 I/O 模块 组合式分立式输入输出模块

【产品详情】

IC200MDD845 是组合 I/O 模块，是艾默生自动化 VersaMax 产品系列的一部分。该模块用作 VersaMax 分布式 I/O 站的一部分，或用作使用本机 CPU 模块的 VersaMax 控制系统的一部分。作为组合 I/O 模块，IC200MDD845共有 24 个输入和输出通道，其中 16 个输入通道支持正极逻辑接线，接受 24 VDC 的标称信号电压;8 个额定电流为 2.0 安培的 A 型或常开 （N.O.） 触点输出，支持 5/24/125 VDC 和 120 / 240 VAC 标称电压的传导，允许电压范围为 0-125 VDC 和 0-265 VAC。 该IC200MDD845的背板电流消耗最大值为 270 mA。

每个输入和输出通道都分配了单独的 LED 状态指示灯，允许对每个模块通道的驱动和通电状态进行本地监控。模块上还存在一个正常 LED，指示背板电源持续向IC200MDD845供电。

IC200MDD845输入通道的导通电流为2.0-5.5 mA，而关断电流为0-0.5 mA。相反，输出负载电流最小为每点10 mA;最大 2.0 安培（5-265 VAC）、2.0 安培（5-30 VDC 和 0.2 安培（31-125 VDC），均适用于电阻负载。输入和输出通道的典型响应时间为 0.5 ms（导通信号转换）和 10 ms（关断信号转换）。

GE Fanuc IC200MDD845混合模块是 GE Fanuc 的产品，是 VersaMax 系列的成员。该模块支持离散输入和输出，提供 2 组 8 个输入和另一组 8 个输出，总共 24 个点。IC200MDD845模块具有 A 型继电器输出，它们单独隔离。

GE Fanuc IC200MDD845模块需要一个IC200CHS系列载波底座。它仅支持输出点的通道间隔离。它不支持缓冲器、内部保险丝或任何其他保护系统。有多个 LED 指示灯显示设备的状态。IC200MDD845混合模块由背板供电，但任何额外的负载都需要第二个电源。该模块从背板电源汲取的总功率取决于活动 I/O 点的数量，其最大电流消耗总计为 270 毫安。可以同时处于活动状态的 I/O 点总数取决于许多因素。IC200MDD845混合模块的输入点电压为 24 伏直流电，输出电压范围为 0 至 125 伏直流电和 0 至 265 伏交流电，频率为 47 至 63 赫兹。

IC200MDD845 组合 I/O 模块 组合式分立式输入输出模块

【英文介绍】

The IC200MDD845 is a combined I/O module that is part of Emerson Automation's VersaMax product family. The module is used as part of a VersaMax distributed I/O station or as part of a VersaMax control system using a native CPU module. As a combined I/O module, IC200MDD845 has 24 input and output channels, of which 16 input channels support positive logic wiring and accept a nominal signal voltage of 24 VDC. Eight Type A or normally open (N.O.) contact outputs rated at 2.0 amps support conduction of 5/24/125 VDC and 120/240 VAC nominal voltages, allowing voltage ranges of 0-125 VDC and 0-265 VAC. The IC200MDD845 has a maximum backplane current consumption of 270 mA.

Each input and output channel is assigned a separate LED status indicator, allowing local monitoring of the drive and power-on status of each module channel. There is also a normal LED on the module indicating that the backplane power supply continues to supply power to the IC200MDD845.

The on-going current of the IC200MDD845 input channel is 2.0-5.5 mA, and the on-off current is 0-0.5 mA. In contrast, the minimum output load current is 10 mA per point; Maximum 2.0 amps (5-265 VAC), 2.0 amps (5-30 VDC), and 0.2 amps (31-125 VDC) are suitable for resistive loads. The typical response time for the input and output channels is 0.5 ms (for signal switching) and 10 ms (for signal switching off).

The GE Fanuc IC200MDD845 hybrid module is a product of GE Fanuc and a member of the VersaMax family. The module supports discrete inputs and outputs, providing 2 sets of 8 inputs and another set of 8 outputs for a total of 24 points. The IC200MDD845 module has Type A relay outputs, which are isolated separately.

The GE Fanuc IC200MDD845 module requires an IC200CHS series carrier base. It supports only inter-channel isolation at the output point. It does not support buffers, internal fuses, or any other protection system. There are multiple LED indicators to show the status of the device. The IC200MDD845 hybrid module is powered by the backplane, but any additional load requires a second power supply. The total power drawn by the module from the backplane power supply depends on the number of active I/O points, and its maximum current consumption totals 270 mA. The total number of I/O points that can be active at the same time depends on many factors. The IC200MDD845 hybrid module has an input point voltage of 24 volts DC and an output voltage range of 0 to 125 volts DC and 0 to 265 volts AC at a frequency of 47 to 63 Hertz.
