IC200MDD841 高速计数器模块  具有混合的分立输入和输出

【产品详情】

IC200MDD841模块是由GE Fanuc制造的高速计数器模块。它属于Versamax系列，具有混合的分立输入和输出，包括12个正逻辑输出和20个正逻辑输入，其中一些可以配置。连接到这些 I/O 连接器的设备有 2 种状态：打开和关闭。GE Fanuc IC200MDD841模块没有保护功能，例如内部保险丝或单个通道的隔离。它支持各种输入和输出配置设置，如脉宽调制、斜坡脉冲序列、脉冲序列和高速计数器。当此模块设置为默认配置时，它有 4 个 Type-A 高速计数器输出和输入。这些高速计数器以 80 kHz 的速度处理脉冲信号。此外，在默认配置中，该模块有 8 个标准输出和 12 个标准输入。

背板为 GE Fanuc IC200MDD841高速计数器模块供电，但单独的电源为所有外部输出设备供电。当此模块连接到额定电压为 5 伏的背板电源时，它消耗的电流为 30 毫安。IC200MDD841模块的输入和输出在 24 伏直流电下工作。该模块的开/关状态电流额定值分别为 3 至 8 毫安/0 至 0.5 毫安。它的尺寸为长 66.8 毫米或 2.63 英寸，宽 110 毫米或 4.3 英寸，深 50 毫米或 1.956 英寸。该高速计数器模块提供错误检测功能，最多可显示 13 个字的状态数据。它具有板载 LED 指示灯，可显示设备状态信息。

IC200MDD841 高速计数器模块  具有混合的分立输入和输出

【英文介绍】

The IC200MDD841 module is a high-speed counter module manufactured by GE Fanuc. It belongs to the Versamax family and has a mixed discrete input and output, including 12 positive logic outputs and 20 positive logic inputs, some of which can be configured. Devices connected to these I/O connectors have two states: on and off. The GE Fanuc IC200MDD841 module has no protection features, such as internal fuses or isolation of individual channels. It supports various input and output configuration Settings such as pulse width modulation, ramp pulse train, pulse train, and high-speed counter. When this module is set to the default configuration, it has 4 Type-A high-speed counter outputs and inputs. These high-speed counters process pulse signals at a speed of 80 kHz. In addition, in the default configuration, the module has 8 standard outputs and 12 standard inputs.

The backplane powers the GE Fanuc IC200MDD841 high-speed counter module, but a separate power supply powers all external output devices. When this module is connected to a backplane power supply rated at 5 volts, it consumes 30 mah of current. The input and output of the IC200MDD841 module operate at 24 volts direct current. The module has on/off state current ratings of 3 to 8 MA /0 to 0.5 MA, respectively. Its dimensions are 66.8 mm or 2.63 inches long, 110 mm or 4.3 inches wide, and 50 mm or 1.956 inches deep. The high-speed counter module provides error detection and displays up to 13 words of status data. It has an on-board LED indicator that displays device status information.

IC200MDD841 高速计数器模块  具有混合的分立输入和输出
