IC200CPUE05 具有内置接口 有两个串行端口

【产品详情】

IC200CPUE05是GE为VersaMax系列设计的CPU。该IC200CPUE05具有内置接口，可作为最多 64 个模块和多达 2048 个 I/O 点的系统控制器。

IC200CPUE05有两个串行端口，分别是针对 SNP 和 RTU 从站、串行 I/O 操作和本地站管理器操作（仅限端口 1）进行软件配置的。当任一端口用于RTU时，需要自动切换到SNP从模式。如果 IC200CPUEO5 处于停止模式，并且 CPU 配置为串行 I/O，则端口将自动返回到 SNP 从站。端口 2 如果 100VDC 时的电源要求为 5 mA 或更低，则可以为外部设备供电。端口 1 是带有 232 针母连接器的 RS-9 端口。如果端口 1 配置为使用 CPU，则可以使用以太网重新启动按钮强制使用。端口 1 将保持其当前模式，直到 PLC 重新通电或按下以太网重启按钮。端口 2 是一个 R3-485 端口，带有一个具有 15 针的母 D-sub 连接器。该端口可用于编程、配置和更新，并可直接连接到 RS-485/RS-232 适配器。

IC200CPUE05 的内置以太网接口使 10BaseT 网络上的通信成为可能。该IC200CPUE05兼容半双工和全双工操作，由于 CPU 的自动感应功能，通常无需任何用户配置。由于这种内置的接口功能，可以处理从主机或其他GE Fanuc PLC访问CPU数据。

IC200CPUE05模块是用户可配置的CPU模块，由GE Fanuc制造，是VersaMax产品线的成员。它是 VersaMax 产品系列的一部分，在 1 个小型设备中提供所有 PLC 功能。此 CPU 模块最多可与 64 个模块和多达 2048 个 I/O 点配合使用。它还带有 2 个串行端口，分别是用于有源串行通信的 RS-485 和 RS-232 端口。IC200CPUE05 CPU模块内置以太网接口，可通过使用编程器软件进行无缝配置。该模块的其他值得注意的规格包括系统闪存和电池备份 RAM。该装置的额定电流为 650 毫安，输入电压额定值为 3.3 伏直流电。它支持DIN导轨安装，并具有128 KB的可配置内存容量。该模块实时时钟的精度为 100 ppm，延迟为 -/+ 9 秒。

GE Fanuc VersaMax IC200CPUE05 CPU 模块有一个超级电容器，如果电源故障，它可以为内存供电约 1 小时。它带有一个运行和停止开关，以帮助控制其操作和应用。它还可用于处理系统中的浮点数据函数。GE Fanuc IC200CPUE05 CPU 模块有 2 组 LED 指示灯，分别位于模块的右下角和上角。LED 指示灯包括“OK”、“PWR”、“FAULT”、“FORCE”、“RUN”、“PORT 1”和“PORT 2”，这些指示灯在模块通电时亮起，并向操作员发送各种更新消息。该CPU模块支持指令表和梯形图编程语言。

IC200CPUE05 具有内置接口 有两个串行端口

【英文介绍】

The IC200CPUE05 is a GE CPU designed for the VersaMax family. The IC200CPUE05 has a built-in interface and can be used as a system controller for up to 64 modules and up to 2048 I/O points.

The IC200CPUE05 has two serial ports that are software-configured for SNP and RTU slave stations, serial I/O operations, and local station manager operations (port 1 only). When either port is used for RTU, it needs to be automatically switched to SNP slave mode. If IC200CPUEO5 is in stop mode and the CPU is configured for serial I/O, the port is automatically returned to the SNP slave station. Port 2 If the power requirement for 100VDC is 5 mA or lower, it can supply power to external devices. Port 1 is an RS-9 port with a 232 pin female connector. If port 1 is configured to use CPU, it can be forced to use the Ethernet restart button. Port 1 will remain in its current mode until the PLC is powered back on or the Ethernet restart button is pressed. Port 2 is an R3-485 port with a 15-pin female D-sub connector. This port can be used for programming, configuration, and updating, and can be connected directly to the RS-485/RS-232 adapter.

The IC200CPUE05's built-in Ethernet interface enables communication over the 10BaseT network. The IC200CPUE05 is compatible with both half-duplex and full-duplex operations, and usually does not require any user configuration due to the CPU's automatic sensing function. Thanks to this built-in interface function, CPU data can be accessed from the host or other GE Fanuc PLCS.

The IC200CPUE05 module is a user-configurable CPU module manufactured by GE Fanuc and is a member of the VersaMax product line. It is part of the VersaMax product family and offers all PLC functions in 1 small device. This CPU module can be used with up to 64 modules and up to 2048 I/O points. It also comes with two serial ports, RS-485 and RS-232 ports for active serial communication. The IC200CPUE05 CPU module has a built-in Ethernet interface that can be seamlessly configured using programmer software. Other notable specifications of the module include system flash memory and battery backup RAM. The unit has a current rating of 650 MA and an input voltage rating of 3.3 volts DC. It supports DIN rail mounting and has a configurable memory capacity of 128 KB. The module's real-time clock has an accuracy of 100 ppm and a delay of -/+ 9 seconds.

The GE Fanuc VersaMax IC200CPUE05 CPU module has a supercapacitor that can power the memory for about 1 hour if the power supply fails. It comes with a run and stop switch to help control its operation and application. It can also be used to handle floating-point data functions in the system. The GE Fanuc IC200CPUE05 CPU module has two sets of LED indicators, which are located in the lower right corner and the upper corner of the module. LED indicators include "OK", "PWR", "FAULT", "FORCE", "RUN", "PORT 1" and "PORT 2", which light up when the module is powered on and send various update messages to the operator. The CPU module supports instruction table and ladder diagram programming languages.

IC200CPUE05 具有内置接口 有两个串行端口
