GE IC755CSS15CDA 电容式显示器

【产品详情】

 IC755CSS15CDA 是由艾默生自动化（前身为 GE Fanuc Automation）制造的 QuickPanel+ 设备。它采用 Windows Compact Embedded （CE） 版本 7 操作系统，具有 15 TFT 英寸彩色显示屏，分辨率为 1024 x 768。它有一个电阻式触摸屏界面。它采用飞思卡尔 i.MX535 1GHz 处理器和 1GB DDR3 SDRAM 构建;512MB SLC NAND 闪存和 512KB 电池备份 SRAM。对于通信，它提供两 （2） 个以太网接口、一 （1） 个支持 RS232 的串行端口和一 （1） 个 RS485 端口。它还提供三 （3） 个 USB 接口。该终端的挡板带有制造商的名称。

IC755CSS15CDA是由艾默生自动化制造的 QuickPanel+ 操作界面 （OI）。此设备是基于微处理器的 OI，托管 Microsoft Windows Embedded Compact 7 操作系统 （OS） 的许可实例。该器件的处理器是Freescale i.MX535，时钟频率为1GHz。它还配备了 2D/3D 图形处理单元和 NEON SIMD 媒体加速器。此外，它还安装了矢量浮点协处理器。

IC755CSS15CDA有一个写有制造商品牌的表圈。该设备可用的显示屏是具有多点触摸屏界面的 15 英寸投射电容式显示器。它的 SVGA 分辨率为 1024 x 768。为了连接到控制器或其他自动化设备，IC755CSS15CDA有两 （2） 个串行接口，其中一 （1） 个接口支持 RS232 点对点连接，另一个接口支持 RS485 菊花链拓扑。内置的双以太网接口支持 10/100 mbps 传输速度，可实现与现代网络和设备的连接。外部外围设备也可以安装到此设备上，例如鼠标和键盘，用于替代输入接口;用于外部数据存储的 USB 闪存驱动器和支持 USB 的打印机。此外，它还支持使用安全数字卡（SD 卡），这些卡可以用作额外的存储位置。

该IC755CSS15CDA通过了多个认证机构的认证和合规性，例如 UL 60950、CE（EN 60950-1、EN 61000-6-4、61000-6-2）、FCC Part15 A 类、IP65F （JEM 1030）、CUL 标志 - US/CAN 2 区、ATEX 2 区*、NEMA 4X 和 RoHS。该设备的冷却方法是自然对流，工作温度为 0°C 至 +55°C.IC755CSS15CDA

端子是 GE Fanuc 即插即用端子。它的屏幕尺寸为 15 英寸，使用投射电容屏。它提供多点触控选项。终端中有一个 ARM Cortex A8 处理器，可满足其所有处理和操作需求。操作终端以 24 伏直流电压运行tage.该终端有一个 GE 字母组合表圈，它装在一个小外壳中。保形涂层外壳甚至可以使用安装垫圈安装在狭小的空间内。这款 15 英寸快速面板的显示分辨率为 SVGA 1024 x 768 像素。端子的背面带有串行 I/O 端口，带有一个 RS-232 5 针连接器和一个 RS-485 通信端口。对于其他外围设备，IC755CSS15CDA端子配备了 2 个 USB 端口（A 型和 B 型）。该终端具有多媒体功能，并具有单个音频输出端口。

IC755CSS15CDA终端有一个 LED 指示灯，可提醒操作员注意不同的事情以及一个板载蜂鸣器。LED 指示灯以琥珀色、绿色和红色亮起，用于不同的事件。该终端使用Microsoft Windows 7操作系统。操作系统支持 Web 浏览和远程网络连接。IC755CSS15CDA终端符合不同的行业标准和合规性等级。它已通过 ATEX Zone 2 环境认证。采用对流冷却方式保持终端温度，设备温度应设置在0至55摄氏度之间。IC755CSS15CDA端子的最大功耗为 30 瓦。该终端支持顺序功能图和功能块图进行编程。

GE IC755CSS15CDA 电容式显示器

【英文介绍】

The IC755CSS15CDA is a QuickPanel+ device manufactured by Emerson Automation (formerly GE Fanuc Automation). It uses the Windows Compact Embedded (CE) version 7 operating system and has a 15 TFT inch color display with a resolution of 1024 x 768. It has a resistive touch screen interface. It is built with a Freescale i.MX535 1GHz processor and 1GB DDR3 SDRAM; 512MB SLC NAND flash and 512KB battery backup SRAM. For communication, it provides two (2) Ethernet interfaces, one (1) serial port with RS232 support, and one (1) RS485 port. It also offers three (3) USB ports. The terminal's baffle bears the manufacturer's name.

The IC755CSS15CDA is the QuickPanel+ Operating Interface (OI) manufactured by Emerson Automation. This device is microprocessor-based OI that hosts a licensed instance of the Microsoft Windows Embedded Compact 7 operating system (OS). The device is powered by a Freescale i.MX535 processor with a clock rate of 1GHz. It also comes with a 2D/3D graphics processing unit and a NEON SIMD media accelerator. In addition, it has a vector floating-point coprocessor installed.

The IC755CSS15CDA has a bezel with the manufacturer's brand on it. The display available for the device is a 15-inch projected capacitive display with a multi-touch screen interface. It has an SVGA resolution of 1024 x 768. For connection to a controller or other automation device, the IC755CSS15CDA has two (2) serial interfaces, one (1) of which supports RS232 point-to-point connection and the other supports RS485 Daisy chain topology. The built-in dual Ethernet interface supports 10/100 mbps transfer speeds for connectivity to modern networks and devices. External peripherals can also be installed on this device, such as a mouse and keyboard, to replace the input interface; USB flash drives for external data storage and USB-enabled printers. In addition, it supports the use of secure digital cards (SD cards), which can be used as additional storage locations.

The IC755CSS15CDA is certified and compliant by multiple certification bodies, Examples include UL 60950, CE (EN 60950-1, EN 61000-6-4, 61000-6-2), FCC Part15 Class A, IP65F (JEM 1030), CUL mark - US/CAN Zone 2, ATEX Zone 2 *, NEMA 4X And RoHS. The cooling method of the equipment is natural convection, and the operating temperature is 0°C to +55°C.IC755CSS15CDA

The terminals are GE Fanuc plug and play terminals. It has a 15-inch screen and uses a projected capacitive screen. It offers multi-touch options. There is an ARM Cortex A8 processor in the terminal that meets all of its processing and operational needs. The operating terminal runs tage at 24 volts DC. The terminal has a GE monogram bezel, which is housed in a small housing. Conformal coated housings can even be installed in tight Spaces using mounting washers. This 15-inch fast panel has a display resolution of SVGA 1024 x 768 pixels. The back of the terminals has serial I/O ports with an RS-232 5-pin connector and an RS-485 communication port. For other peripherals, the IC755CSS15CDA terminal is equipped with 2 USB ports (Type A and Type B). The terminal has multimedia capabilities and a single audio output port.

The IC755CSS15CDA terminal has an LED indicator to alert the operator to different things as well as an onboard buzzer. LED lights light up in amber, green and red for different events. The terminal uses Microsoft Windows 7. The operating system supports Web browsing and remote network connection. The IC755CSS15CDA terminal complies with different industry standards and levels of compliance. It is ATEX Zone 2 environment certified. Use convection cooling to maintain the terminal temperature, and the device temperature should be set between 0 and 55 degrees Celsius. The IC755CSS15CDA terminal has a maximum power consumption of 30 watts. The terminal supports sequential function diagram and function block diagram for programming.

GE IC755CSS15CDA 电容式显示器
